1.

Symbols used

1.1

In the documentation

1.1.1 Warning notices -
Structure and meaning
Warning notices warn of dangers to the user or people
in the vicinity. Warning notices also indicate the con-
sequences of the hazard as well as preventive action.
Warning notices have the following structure:
KEY WORD – Nature and source of hazard!
Warning
symbol
Consequences of hazard in the event of fail-
ure to observe action and information given.
¶
Hazard prevention action and information.
The key word indicates the likelihood of occurrence and
the severity of the hazard in the event of non-obser-
vance:
Key word Probability of
occurrence
DANGER Immediate impend-
ing danger
WARNING Possible impending
danger
CAUTION Possible dangerous
situation
1.1.2 Symbols in this documentation
Symbol Designation Explanation
Attention Warns about possible property damage.
!
Information Practical hints and other
i
useful information.
1. Multi-step Instruction consisting of several steps.
2. operation
One-step Instruction consisting of one step.
e
operation
Intermediate An instruction produces a visible inter-

result mediate result.
Final result There is a visible final result on com-
"
pletion of the instruction.
1.2

On the product

!
Observe all warning notices on products and ensure
they remain legible.
Disposal
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
|
1 689 989 223 2016-07-20
Severity of danger if in-
structions not observed
Death or severe injury
Death or severe injury
Minor injury
2.

User information

2.1 Important notes
Important information on copyright, liability and warran-
ty provisions, as well as on equipment users and com-
pany obligations, can be found in the separate manual
"Important notes on and safety instructions for Bosch
Test Equipment". These instructions must be carefully
studied prior to start-up, connection and operation of
the KTS 560 / 590 (KTS 5a Series) and must always be
heeded.
2.2

Safety instructions

All the pertinent safety instructions can be found
in the separate manual "Important notes on and
safety instructions for Bosch Test Equipment".
These instructions must be carefully studied pri-
or to start-up, connection and operation of the
KTS 560 / 590 (KTS 5a Series) and must always be heed-
ed.
2.3

Electromagnetic compatibility (EMC)

The KTS 560 / 590 (KTS 5a Series) satisfies the require-
ments of the EMC directive 2004/108/EG.
i
The KTS 560 / 590 (KTS 5a Series) is a class A
product as defined by EN 61326-1:2006. The
KTS 560 / 590 (KTS 5a Series) may cause high-fre-
quency household interference (radio interference)
so that interference suppression may be necessary.
In such cases the user may be required to take the
appropriate action.
2.4 Measuring category according to
EN 61010-2-030:2010
EN 61010-1:2010 specifies the general safety require-
ments for electrical testers and measuring devices and
defines the measuring categories from 0 to IV in the
section EN 61010-2-030:2010.
The KTS 560 / 590 (KTS 5a Series) is intended for use in
measuring category 0, i.e. for measurements in circuits
with no direct connection to the mains voltage.
