Technical Specifications - STEINEL HF 360 COM 1 Information

Electrical installation/Automatic mode
In selecting the wiring leads, it is section 6 of VDE 0100 520, a multi-
important to meet the wiring ple-core lead containing both the
regulations laid down in VDE 0100 mains voltage leads and the con-
(see Safety warnings on page 19). trol leads (e.g. NYM 5 × 1.52) may
The following applies to wiring be used for wiring between the
presence detectors: According to sensor and electronic ballast. The
L
N
COM 1 COM 2
L L
N N
P
P S N
COM1
L L'
COM 1 AP
L
N
1-10V
max. 100 mA
L L
N N
P S N
DIM
1-10V
L L'
+ –
L
N
mains connection lead must be no
greater than 10 mm in diameter.
The clamping range of the mains
COM1
terminal is designed for a maxi-
mum of 2 × 1.5 mm
2
or 1 × 2.5 mm .
2
L
N
L
P
N
P S N
COM1
L L'
P S N
COM1
L L'
DIM
L
N
DIM
1-10V
max. 100 mA
L
N
P S N
DIM
1-10V
L L'
+ –
L
N
P S N
DIM
1-10V
L L'
+ –
- 22 -
1-10V
L

Technical Specifications

N
P
Dimensions
(w × h × d)
P S N
Supply voltage
L L' Capacity, switching output 1
(COM 1/COM 2)
Electronic ballast:
(COM 1/COM 1 AP/
COM 2/DIM)
L
Capacity, switching output 2
N
P
(COM 2 only) (HF 360 only)
Application
Mounting height
(mounted to ceiling)
Detection angle
L
N
Reach
P S N
Switching output 1
1-10V
L L'
+ – Time setting
Switching output 2
Time setting
(HF 360 only)
DIM:
Time setting
Control output
Sensor system
Function setting by
DIP switches
Parallel connections
L
User-friendly setting capability Teach-in (with optional remote control RC3)
N
Light-level setting
IP rating
Safety class
Temperature range
Housing
HF 360 Dual HF
120 × 120 × 56 mm 120 × 120 × 76 mm
230 – 240 V, 50 Hz / 60 Hz
Relay 230 V
Resistive load 2000 W max. (cos ϕ = 1)
1000 VA max. (cos ϕ = 0,5)
Max. 'ON' current 800 A/200 μs
30 × (1 × 18 W), 25 × (2 × 18 W)
25 × (1 × 36 W), 15 × (2 × 36 W)
20 × (1 × 58 W), 10 × (2 × 58 W)
Pay attention to specific 'ON' currents of electronic ballasts!
A relay or contactor must be provided on line side for higher switching
capacities.
Presence
230 W max. / 230 V
1A max. (cos ϕ = 1) for HVAC (heating/ventilation/air-conditioning)
indoors
2.5 m – 3.5 m ceiling height
HF 360 Dual HF
360° with 140° aperture angle see diagrams on p. 21
also through glass, wood and also through glass, wood and stud
stud walls. 1 or 2 detection direc- walls
tions can be masked out for ad-
justment to the room situation.
HF 360 Dual HF
8 m max. all round, 10 × 3 m max. in each direction,
electronically and infinitely electronically and infinitely
variable adjustable
30 sec. – 30 min., pulse mode (approx. 2 sec.)
IQ mode (automatic adjustment to use profile)
COM2 only for HVAC
0 sec. – 10 min. switch-'ON' delay
1 min. – 2 h stay-'ON' time
Automatic room surveillance
30 sec. - 30 min.
IQ mode (automatic adjustment to use profile)
1 – 10 V / max. of 50 electronic ballasts, max. of 100 mA
High-frequency 5.8 GHz, transmission power < 1mW
DIP 1 Normal / test mode
DIP 2 Semi- / fully automatic mode
DIP 3 Button / switch mode
DIP 4 'ON' button / 'ON'-'OFF' button
DIP 5 Constant-lighting control 'ON'-'OFF' (DIM)
Master/slave
Master/master
10 – 1000 lux, ∞ / daylight
DIM 100 – 1000 lux
IP 20 (IP 54 with surface-mounted box)
II
0° to +40° C
UV-resistant, paintable
- 23 -
