Trox FSL-CONTROL II Installations- Und Konfigurationsanleitung Seite 71

Register Nutzdaten
Adresse Name
7 RelHumid
8 StartPCM
9 VOC_Room
10 VOC_Outside
11 Fire
12 Window
13 ExtraTime
14 ChangeOver
15 FanSpeed
16 DischAirTemp
17 ActMode
18 ActExtraTime
19 EffectSetpt
20 ActWindow
21 ActFanSpeed
22 ActApplicMode
23 ActOutsideTemp
24 SetptOffset
25 ActRoomTemp
26 ActRelHumid
27 ActVOC_Room
28 FAlarm
29 Alarm1
Richtung Modbus
EM / GG Werte
EM -> GG 0 - 100
EM -> GG 0 - 1
EM -> GG uint16
EM -> GG uint16
EM -> GG 0 - 1
EM -> GG 0 - 1
EM -> GG 0 - 1
EM -> GG 0 - 2
EM -> GG siehe
Codierung
GG -> EM sint16
GG -> EM 255,
0, 1, 2, 3
GG -> EM 0 - 1
GG -> EM sint16
GG -> EM 0 - 1
GG -> EM siehe
Codierung
GG -> EM 255,
0 – 10,
12 – 14
GG -> EM sint16
GG -> EM sint16
GG -> EM sint16
GG -> EM 0 - 100
GG -> EM uint16
GG -> EM 0 - 1
GG -> EM 0 - 1
Einzelraumregelung FSL‑CONTROL II
Konfiguration Schnittstellen / GLT
Modbus SPI-Bytes
Default
0 Low, (High=0)
0 Low, (High=0)
0 High, Low
0 High, Low
0 Low, (High=0)
0 Low, (High=0)
0 Low, (High=0)
0 Low, (High=0)
0; 0 High, Low
0x7FFF High, Low
255 Low, (High=0)
0 Low, (High=0)
0x7FFF High, Low
0 Low, (High=0)
0; 0 High, Low
255 Low, (High=0)
0x7FFF High, Low
0x7FFF High, Low
0x7FFF High, Low
0 Low, (High=0)
0 High, Low
0 Low, (High=0)
0 Low, (High=0)
8
Modbus RTU Schnittstelle
Codierung / Einheit /
Auflösung
Einheit %
Einheit ppm
Einheit ppm
0 = off
1 = cooling
2 = heating
High-Byte: Wert,
Low-Byte: 0 Auto, 1 Hand
0x0001 = 0; 1 = Off
0x2801 = 40; 1 = Level 1
0x5001 = 80; 1 = Level 2
0x7801 = 120; 1 = Level 3
0xA001 = 160; 1 = Level 4
0xC801 = 200; 1 = Level 5
0x0000 = 0; 0 = Auto
Einheit 0,01°C
255 = Nul
0 = Occupied
1 = Unoccupied
2 = Boost
3 = Standby
Einheit 0,01°C
High-Byte: Wert,
Low-Byte: 0 Auto, 1 Hand
0x0001 = 0; 1 = Off, Hand
0x2801 = 40; 1 = Level 1
0x5001 = 80; 1 = Level 2
0x7801 = 120; 1 = Level 3
0xA001 = 160; 1 = Level 4
0xC801 = 200; 1 = Level 5
0x0000 = 0; 0 = Off, Auto
0x2800 = 40; 0 = Level 1
0x5000 = 80; 0 = Level 2
0x7800 = 120; 0 = Level 3
0xA000 = 160; 0 = Level 4
0xC800 = 200; 0 = Level 5
255 = HVAC_NUL
0 = HVAC_AUTO
1 = HVAC_HEAT
2 = HVAC_MRNG_WRMUP
3 = HVAC_COOL
4 = HVAC_NIGHT_PURGE
5 = HVAC_PRE_COOL
6 = HVAC_OFF
7 = HVAC_TEST
8 = HVAC_EMERG_HEAT
9 = HVAC_FAN_ONLY
10 = HVAC_FREE_COOL
12 = HVAC_MAXHEAT
13 = HVAC_ECONOMY
14 = HVAC_DEHUMID
Einheit 0,01°C
Einheit 0,01°C
Einheit 0,01°C
Einheit %
Einheit ppm
71
