EMV-Allgemeine Daten
Emission Übersicht
RF-Emission following
RF-Emission following
Generation of mains harmonics following
Generation of mains harmonics following
EMV-Tabelle 202
Susceptibility
ESD IEC 61000-4-2
Bursts IEC 61000-4-4
Surges IEC 61000-4-5
Voltage drops etc.
IEC 61000-4-11
H-field at 50/60Hz IEC 61000-4-8
EMV-Tabelle 204
Susceptibility
Conducted rf
IEC 61000-4-6
Radiated rf
IEC 61000-4-3
EMV-Tabelle 206
Output power of transmitter (W)
0,01
0,1
1
10
100
A) Optinales Zubehör
B) Optionales Zubehör
Technische Änderungen ohne Voranmeldung vorbehalten
46
(aus engl. Prüfbereicht, Deailangaben)
150kHz to 80MHz
0,12m
0,37m
1,17m
3,69m
11,67m
Konformität
EN 55011
Group 1
EN 55011
Class B
IEC 61000-3-2
Class A
IEC 61000-3-3
none
IEC 60601-test level actual level
±6kV cd
±6kV cd
±8kV ad
±8kV ad
±2kV mains
±2kV mains
±1kV I/O
±1kV I/O
±1kV dm
±1kV dm
±2kV cm
±2kV cm
Reduction to
5% for 10ms/ positive amplitude
5% for 10ms/ positive amplitude
5% for 10ms/ negative amplitude
40% for 100ms
30% for 500ms
0% for 5000ms
3A/m
IEC 60601-test level
3Veff
150kHz to 80 MHz
3Veff
80 MHz to 2,5 GHz
Safety distance depending on frequency/m
80MHz to 800MHz
0,12m
0,37m
1,17m
3,69m
11,67m
DIETZ GmbH | CYRIUS E-Fahrer | VERSION 1.2.6. DE
Actual level
3V
3V/m
800MHz to 2,5 GHz
0,24m
0,74m
2,34m
7,38m
23,34m
