7.2. Quick-access buttons
Using the F1 / F2 / F3 buttons, you can easily control preset devices. If the default F1 (Lights) /
F2 (Attraction) / F3 (Filtration) functions are not up to your choice, the button functions can
be reprogrammed and/or renamed.
7.2.1. Changing the quick-access button function
With RC in the sleep mode, press and hold "F2" + press " " for at least 3 seconds. The display
will light up and the actual button configuration will be displayed:
Lights F1
Attraction
Filtration
Attraction 2
Lights
Attraction F1
Filtration
Attraction 2
2
7.2.2. Renaming the quick-access button functions
You can also rename the functions, should you not like the preset names.
Renaming the quick-access functions:
In the sleep mode (display off) press and hold the "F3" + press " " for at least 3 seconds. The
display will light up and current configuration will be displayed, e.g.:
>Lights
Attraction
Attraction 2
>Shower
Massage
Attraction
7.3. DIN Module configuration (DIP switch)
Operating functions of the DIN module (heating priority, flow switch, dosing stations /
chlorinators) can be configured with a DIP switch.
7.4. Konfigurační nabídka (menu)
ATTENTION – with DIP switch 4 (heating priority) OFF, the antifreeze protection and cell protection with water
temperatures under 14 °C will be deactivated! Temperature readings at 10, 14 and 20:00 hours will remain active.
a)
F2
F3
b)
F3
Note:
If you assign the same function to two buttons, (e.g. Lights for both F1 and
F2
F2 buttons), both buttons will control the same function.
a)
b)
c)
d)
e)
f)
g)
h)
With repeated pressing of the "F1", "F2" or "F3" buttons the new
function will be assigned,
Confirm changes with the "SET/SEND" button, the display will
automatically refresh,
Activate the renaming function by pressing the "ENT/ESC",
Select desired letter using the "V" or "ꓥ" buttons,
Move to next position with "<>",
Use "F1" to switch between UPPERCASE/lowercase,
Insert space with the "F2",
Select desired digit by repeated pressing of "F3",
Press "SET/SEND" to confirm and save changes, the display will
automatically refresh,
Press "ENT/ESC" to skip (changes will not be saved).
1
2-3 Dosing station <> saltwater chlorinator
4
Flow switch – default OFF
Heating priority – default ON
