Important! Due to the high risk of bodily injury to the
user, the equipment may not be used to grind up
branch or hedge clippings. Moreover, the equipment
may not be used as a power cultivator to level out
high areas such as mole hills.
For safety reasons, the scarifier may not be used as
a drive unit for other equipment or toolkits of any
kind, unless specifically advised to do so by the
manufacturer.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.

4. Technical data

Voltage:
Power consumption:
Idle speed:
Working width:
Number of blades
Number of claws:
Scarifying depth:
L sound pressure level:
pA
L sound power level:
WA
Vibration on the shaft a
hv
K uncertainty
Protection class:
Protection type:
Weight
Sound and vibration values were measured in
accordance with EN ISO 3744: 1995, EN ISO 11201:
1995, EN 1033:1995.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
n
order.
Service and clean the appliance regularly.
n
Adapt your working style to suit the appliance.
n
16
Do not overload the appliance.
n
Have the appliance serviced whenever
n
necessary.
Switch the appliance off when it is not in use.
n
Wear protective gloves.
n
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain residual
risks cannot be rules out. The following hazards
may arise in connection with the equipment's
construction and layout:
1. Damage to hearing if no suitable ear protection is
used.
2. Health damage caused by hand-arm vibrations if
the equipment is used over a prolonged period or
is not properly guided and maintained.
Warning! This equipment generates an electromag-
netic field during operation. Under certain circum-
stances this field may actively or passively impede
medical implants. To reduce the risk of serious or fatal
injuries, we recommend persons with medical
implants to consult their doctor and the manufacturer
of the medical implant prior to using the equipment.
230 V ~ 50 Hz

5. Before starting the equipment

1400 W
3300/min The scarifier is delivered unassembled. The grass
basket and the complete push bar must be
35 cm
assembled and mounted before using the scarifier.
20 pieces
Follow the operating instructions step-by-step and
use the pictures provided as a visual guide to easily
26
assemble the machine.
- 3 / 3 / 6 / 9 mm
72.5 dB(A)
Fitting the rear wheels (see Fig. 3 and Fig. 4)
Insert the axles of the rear wheels into the
n
99 dB(A)
openings provided (Fig. 3 / Item A).
5.489 m/s
2
Secure the wheels with the screws provided .
n
1.5 m/s 2
(Fig. 4/ Item 19)
II /
Fitting the push bar brackets (see Figs. 5 and 6)
IPX4
Remove the quick-release lever (Fig. 5/Item 13)
n
11,6 kg
and the washer (Fig. 5/Item 17)
Connect the push bar bracket (Fig. 5/Item 7) to
n
the fastening screw. Make sure that the curve in
the tube (Fig. 6/Item A) is on the outside.
Now put the washer back on and tighten with the
n
quick-release lever.
Important. The same tilt angle must be set for both
push bar brackets!
