Assembly - Jarolift Basic Originalmontageanleitung

Drilling the drive feed-through
WARNUNG!
Damage to the operating elements or motor
cable due to an unclean drive feed-through!
■
Clean the feed-through of chips and dirt!
■
Check that the feed-through is aligned with the drive
outlet, and rework if necessary! Misalignment leads to
increased wear on the drive.
■
Avoid or remove sharp edges at the feed-through!
Attaching the guide rails
Attach the guide rails to the guide rail mounts on the roller
shutter box. Make sure that the curtain can slide smoothly
into the guiderail.
CAUTION!
Push the guide rails all the way to the box! Be
careful not to damage the inlet funnel.

ASSEMBLY
