SR SUNTOUR - OWNERS MANUAL
ADJUSTABLE AIR VALVE
There are some frames which are
giving you a hard time when you
are trying to inflate your rear shock
because the air valve can not be
reached very easy. To make your life
easier we developed a new air valve
which can be rotated 360degrees.
This makes it possible to place your
air valve in every position you want to
have it. To adjust your air valve please
follow the hereafter
steps:
1. Release all air off your rear shock
2. Adjust your rear shock to every
position you want to have it
3. Inflate your rear shock again
Please note that the air valve sits very tight on top off the main body to make sure
the rear shock is sealed. As a result of this, it requires a little bit of power to twist the
air valve. Please do not use any kind of tools to adust the air valve. This fears the risk
that the valve itself will brake away.

REBOUND DAMPING ADJUST

The rebound function of SR SUNTOUR rear shocks allows you to tune your shock according to your
personal preferences and the terrain you are riding on. This function enables you to control the
speed of your rear shock's rebound after it's being compressed.
If you are going to ride on a terrain with a lot of small and fast bumps, we recommend to increase
your rear shocks rebound speed. Otherwise it implies the risk that your bike can not follow the
bumps which could result into a loss of control of your bike. If you are going to ride on a flat terre-
ain with slow bumps you should decrease your rear shocks rebound speed. This will help to abord
the teetering of your swing arm.
RS EPICON LOD / AM LODP
RS EPICON DA
RS RAIDON DA
RS DUROLUX RCA
In order to increase the rebound speed
of your rear shock you have to turn the
adjuster knob counter clock. To decrease
the speed you have to turn it counter-
clockwise.
8
English
mentioned
RS EPICON / RS RAIDON / RS DUROLUX
RS11/RS9-EPICON AM LODP/ LOD /DA
Rebound Adjust
