Damaged electrical connection cable.
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Pressure points, where connection cables are
passed through windows or doors,
• Kinks where the connection cable has been improp-
erly fastened or routed,
• Places where the connection cables have been cut
due to being driven over,
• Insulation damage due to being ripped out of the wall
socket,
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage
regularly. Ensure that the connection cables are dis-
connected from electrical power when checking for
damage.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the designation H05VV-F.
The printing of the type designation on the connection
cable is mandatory.
AC motor
• The mains voltage must be 220-240 V~.
• Extension cables up to 25 m long must have a
cross-section of 1.5 mm².
Connection type Y
If it is necessary to replace the mains connection ca-
ble, this must be done by the manufacturer or their rep-
resentative to avoid safety hazards.
Connections and repair work on the electrical equip-
ment may only be carried out by electricians.
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Product data - type plate
• Motor data - type plate

12. Cleaning, maintenance and storage

m Attention!
Pull out the mains plug before carrying out any cleaning
or maintenance work! Danger of injury due to electric
shocks!
m Attention!
Wait until the product has cooled down completely!
Danger of burning!
m Attention!
Depressurise the product before carrying out any
cleaning or maintenance work! Danger of injury!
12.1 Cleaning
• Keep the product as free of dust and dirt as possible.
Rub the product clean with a clean cloth or blow it off
with compressed air at low pressure.
• We recommend that you clean the product directly
after every use.
• Clean the product at regular intervals using a damp
cloth and a little soft soap. Do not use any cleaning
products or solvents; they could attack the plastic
parts of the product. Make sure that no water can
penetrate into the product interior.
• The hose and injection tools must be disconnected
from the compressor before cleaning. The compres-
sor must not be cleaned with water, solvents or similar.
12.2 Storage (Fig. 3 + 4)
m Attention! Pull out the mains plug. Store the
compressor in such a way that it cannot be used
by unauthorised persons.
m Attention!
Store the compressor only in dry locations that
are inaccessible for unauthorised persons.
• The 230 V mains cable (11) can be stowed on the
holder (6) on the right side.
• The 12 V connection cable (12) can be stowed on the
holder (1) on the left side.
• The compressed air hose (14) can be stowed in the
storage compartment (13) on the left side.
• The adapter for tyre valves (9), the conical adapter
(8) and the ball needle (10) can be stowed in the stor-
age compartment (15). (Fig. 4)
12.3 Transport (Fig. 1)
The product can be transported with the carry handle (2).

12.4 Service information

With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consumables.
Wearing parts*: Belts and couplers
* may not be included in the scope of delivery!
www.scheppach.com GB | 25
