Connection and operation

Warning
Read warning notice
and instruction manual
carefully prior to initial
operation and save the
information for later use.
Unpacking the AUTOMIG 273i
2
After unpacking and prior to use, proceed as
follows (see drawing):
Please note:
AUTOMIG 183i/233i has a permanently fixed
2
trolley.
Permissible installation
Mains connection
Connect the machine to the correct mains supply.
Please read the type plate (U
the machine.
yellow/green
brown
black
grey
yellow/green
brown
black
grey
Important!
In order to avoid destruction
of plugs and cables, good
electric contact is required
when connecting earth
cables and welding hoses to
the machine.
Connection of welding hose
Lifting instructions
Lifting hooks can be used at the sack barrow for
lifting with a crane (figure 1).
The trolley with four wheels cannot be lifted
with a crane but only manually using the handle
(figure 2).
The machine must not be lifted with a mounted
gas cylinder!
) on the rear side of Fig. 1
1
3x200-440V
L1
L2
L3
N
1x200-440V
L
N
Fig. 2
