To start the power tool (Figure B), press the on/off switch (4) and hold it
down.
To lock the pressed on/off switch (4), press the lock button (5).
To turn off the locked switch, press the on/off switch (4) and release it.
Do not use the hammer if the switch is damaged.
HAMMER OPERATION, DEMOLITION
Hold the hammer firmly with both hands and start it. For best performance,
apply a steady, moderate pressure (not excessive) to the hammer, as this
will reduce its efficiency. The hammer has been properly lubricated by the
manufacturer and is ready for use. A hammer filled with a permanent
lubricant requires some time to warm up, depending on the ambient
temperature. If the hammer is left unused for a long period of time or is
used at low temperatures, allow it to run without load for 2-3 minutes.
Sharpened working tools increase work efficiency. Uncontaminated
ventilation openings reduce the risk of motor overheating.
During operation, small amounts of grease may escape from
between the working tool and the handle. This is normal.
OPERATION AND MAINTENANCE
WARNING! Before performing any adjustment, maintenance or
repair work, disconnect the device from the power supply!
MAINTENANCE AND STORAGE
•
The hammer should be cleaned with a soft brush or a low-
pressure jet of compressed air.
•
Do not use water or chemical cleaning agents to clean the
hammer.
•
Keep the motor ventilation slots clear.
•
If excessive sparking occurs on the commutator, have the
condition of the motor carbon brushes checked by a qualified
person.
•
The replacement of the power cord or other repairs must only be
carried out by an authorised service workshop.
•
Always store the hammer in a dry place out of the reach of
children.
LUBRICATION OF POWER TOOLS
When the tool has been in operation for more than 60 hours, it must be
lubricated. Open the lubrication hole cover by unscrewing the cover
screws with a screwdriver, then wipe off the used grease with a towel. Use
30 grams of grease designed for lubricating hammers to lubricate the
power tool.
The replacement of carbon brushes should only be carried out by a
qualified person using original parts. Any faults should be repaired
by an authorised service centre.
RATING DATA
Demolition hammer 58G868
Parameter
Power supply
Power frequency
Rated power
Impact frequency
Impact energy
Handle type
Protection class
Weight (without accessories)
58G868 refers to both the type and designation of the device
NOISE AND VIBRATION DATA
Sound pressure level
Sound power level
Vibration acceleration value (main
handle)
Vibration acceleration value (auxiliary
handle)
Information on noise and vibration
The noise emitted by the device is described by: the emitted sound
pressure level Lp and the sound power level Lw
A
measurement uncertainty). The vibrations emitted by the device are
described by the vibration acceleration value a
measurement uncertainty).
The values given in this manual: emitted sound pressure level Lp
power level Lw and vibration acceleration value a
A
Value
230 V AC
50 Hz
1700 W
-1
1500 min
45J
HEX
II
14 kg
L = 95 dB(A) K=1,67 dB(A)
PA
L = 103 dB(A) K=1.67 dB(A)
WA
2
a = 17.21 m/s2 K=1.5 m/s
h
2
a = 14.95 m/s2 K=1.5 m/s
h
(where K denotes the
A
(where K denotes the
h
, sound
A
have been measured
h
in accordance with EN 62841-2-6. The vibration level a(
compare devices and for a preliminary assessment of vibration exposure.
The vibration level given is only representative for the basic application of
the device. If the device is used for other applications or with other tools,
the vibration level may change. Insufficient or infrequent maintenance of
the device will result in higher vibration levels. The reasons given above
may increase exposure to vibration during the entire working period.
To accurately estimate vibration exposure, consider periods when
the device is switched off or when it is switched on but not used for
work. After carefully estimating all factors, the total vibration
exposure may be significantly lower.
To protect the user from the effects of vibration, additional safety
measures should be taken, such as: regular maintenance of the device
and work tools, ensuring adequate hand temperature and proper work
organisation.
ENVIRONMENTAL PROTECTION
Electrically powered products should not be disposed of with
household waste, but should be taken to a suitable disposal facility.
Information on disposal can be obtained from the product retailer or
local authorities. Used electrical and electronic equipment contains
substances that are harmful to the environment. Equipment that is not
recycled poses a potential threat to the environment and human
health.
"GTX Poland Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with its
registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "GTX Poland") hereby
informs that all copyrights to the content of this manual (hereinafter: "Manual"), including,
but not limited to, its text, photographs, diagrams, drawings, as well as its composition,
belong exclusively to GTX Poland and are protected by law in accordance with the Act of
4 February 1994 on copyright and related rights (i.e. Journal of Laws 2006 No. 90, item
631, as amended). Copying, processing, publishing or modifying the entire Manual or any
of its elements for commercial purposes without the written consent of GTX Poland is
strictly prohibited and may result in civil and criminal liability.
EC Declaration of Conformity
Manufacturer: GTX Poland Sp. z o.o. Sp. k.,
Pograniczna Street 2/4 02-285 Warsaw
Product: Demolition hammer
Model: 58G868
Trade name: GRAPHITE
Serial number: 00001 ÷ 99999
This declaration of conformity is issued under the sole responsibility of
the manufacturer.
The product described above complies with the following documents:
Machinery Directive 2006/42/EC
Electromagnetic Compatibility Directive 2014/30/EU
RoHS Directive 2011/65/EU amended by Directive 2015/863/EU
And meets the requirements of the following standards:
EN 62841-1:2015+A11; EN IEC 62841-2-6:2020+A11
EN IEC 55014-1:2021; EN IEC 55014-2:2021; EN IEC 61000-3-
2:2019+A1; EN 61000-3-3:2013+A1+A2
EN IEC 63000:2018
This declaration applies only to the machine in the condition in which it was
placed on the market and does not cover components
added by the end user or subsequent actions carried out by the end user.
Name and address of the person authorised to prepare the technical
documentation who is resident or established in the EU:
Signed on behalf of:
GTX Poland Sp. z o.o. Sp.k.
Pograniczna Street 2/4 02-285 Warsaw
Paweł Kowalski
Quality Representative of GTX POLAND
Warsaw, 24 April 2025
ПЕРЕКЛАД ОРИГІНАЛЬНИХ ІНСТРУКЦІЙ
ПОПЕРЕДЖЕННЯ Прочитайте всі попередження щодо безпеки,
інструкції, ілюстрації та технічні характеристики, що надаються
разом із цим електроінструментом. Недотримання всіх наведених
нижче інструкцій може призвести до ураження електричним струмом,
пожежі та/або серйозних травм.
Збережіть усі попередження та інструкції для подальшого
використання.
7
