Connecting the winch

1 Turn the clutch to the „CLUTCH OUT" position to disengage it.
2 Use the hand saver tool to grip the cable assembly, then pull the cable
to the required length and attach it to the object being pulled.
3
Plug the handheld controller into the control box.
4 Briefly test the winch by running it in both directions for one to two
seconds each.
5
While standing clear of the winching path, operate the handheld
controller in the desired direction. To reverse, wait until the motor stops
completely before switching directions.
6 Once winching is finished, unplug the handheld controller and place the
protective cover back on the socket.
90 Subject to technical changes
WARNING – The switch must be positioned in a way that does not
interfere with the safe operation of the vehicle or the winch. Ensure that
the wiring does not come into contact with any moving components or
sharp edges, such as the engine, winch drum, wire rope, straps, suspen-
sion, brakes, exhaust, or steering system.
