Replacing the rope

1 Place the clutch on the 'OUT' position.
2 Take off the rope unit to its full length. You can now see how the
existing rope is connected to the drum.
3 Remove the old rope unit and attach a new unit to the drum
in the same way.
4
Make sure the new rope is wound up in the same direction as
the old rope. The rope should leave the drum from the bottom,
under the drum.
5 Place the clutch on the 'IN' position
6
Wrap the rope unit on the drum. On the first five revolutions,
be careful not to buckle the rope. Then the rope must be wrapped
under a load of at least 5% of the nominal pull force on the drum.
WARNING – swap the rope only with the identical spare parts
recommended by the manufacturer.
