B5 Motor protection filter
B6 Floating nozzle (for wet vacuuming only)
C. HOSE
The section encompasses the suction hose with grip and suction pipes. The suction end
is connected with the container section by inserting the hose into the suction inlet. The
suction pipe is connected with the grip. The grip contains the suction power control. The
hose can be placed on the motor set by means of the parking clip.
C1 Elastic suction hose
C2 Metal telescopic tube
D. ADDITIONAL ACCESSORIES
There are many available accessories for various cleaning needs:
D1 Accessories holder
D2 Floor and carpet nozzle
D3 Crevice nozzle
D4 Round brush
D5 Narrow brush
D6 Air refresher

PREPARATION FOR USE

CAUTION! Remove all bags, stickers, tapes and transport safety devices from the vac-
uum cleaner and its accessories before the first use.
CAUTION! If the suction power of the vacuum cleaner decreased significantly, then the
pipe and/or suction end and/or diffuser port became clogged. Unclog the pipe and/or
suction end and/or diffuser port.
CAUTION! Do not insert the plug into the mains socket until the appliance is complete-
ly ready for use
1. Raise the handle A6. Lift the container B1 holding its handle B3.
2. Remove the container lid B2. Take out the DWS diffuser B4.
3. Check the parts and accessories taken out from the con-
tainer (against those shown in the user manual) to make sure
that none is missing or damaged. The filter B5 must be prop-
erly installed on the motor air inlet (Fig. 1).
4. If you want to use the vacuum cleaner at once, pour water into
the container B1. The maximum water level in the container is 1.2L and it is marked with a line.
Avoid filling the container below or above the required level because this
can cause damage to the vacuum cleaner! While wet vacuuming DO NOT
POUR the water into the container.
5. Sprinkle the HEPA 13 filter with a small amount of aromatic oil in order to have a pleasant smell
in the room.
34
Fig.1
