6. Place the diffuser B4 in the proper place in the water container B1 or install the B6 floating
nozzle (while wet vacuuming) – (Fig.2.) Install the water container lid
B2 back.
7. Then, place the container B1 onto the vacuum cleaner housing A10
and lower the handle A6. Place the suction hose fixing clip C1 in the
connection port A5. You will hear a click when the parts become
blocked. In order to disassembly those parts press the buttons on
the fixing clip and remove the suction hose from the connection
port.

DRY VACUUMING

Install the DWS diffuser B1 in the water container B4 and pour the water avoiding to exceed the
MAX 1.2l line marked in the container..
1. Choose the most suitable accessories to perform cleaning works. The vacuum cleaner is
equipped with rubberised wheels to prevent the vacuumed surfaces from scratching. In order
to obtain the effective cleaning, use the accessories in the following manner:
a. Floor and carpet nozzle D2 to vacuum carpets and hard surfaces, such as ceramic tiles and
terracotta.
a. Crevice nozzle D3 to remove dust from hardly accessible places. .
b. Narrow brush D4 to clean window shutters, stands, clothes, electrical equipment, lamp-
shades furniture, etc.
c. Round brush D5 to clean curtains, upholstery, etc.
d. Telescopic tube C2 that is directly connected to the suction hose C1 should be used for
cleaning large stains, such as residues, chips, etc.
e. Small turbo brush D7 to effectively clean such surfaces as sofa, armchairs, as well as car
upholstery.
2. Insert the vacuum cleaner plug into the mains socket and turn on the appliance by pressing
(ON/OFF) switch button A1.
3. After finishing the vacuuming process, turn off the vacuum cleaner by pressing the (ON/OFF)
switch button A1. Remove the plug A9 from the mains socket and rewind the power cord by
pressing the cord rewind button A2.
4. Carry the vacuum cleaner by holding its handle A6.
CAUTION: In the dry vacuuming mode vacuum dry surfaces only. If there
is a foam in the container (e.g. as a result of sucking in foaming substances),
turn off the appliance and change the water immediately.

WET VACUUMING

1. Install the floating nozzle B6 in your vacuum cleaner in the place of the diffuser B4 and do not
pour the water into the container B1.
2. During wet vacuuming the vacuum cleaner can suck in the water. The suction of solid fractions
should be limited because in this mode it is the suction of water, e.g. incidentally spilled on the
floor or left after cleaning the floorings and floors, etc., that forms the priority for the vacuum
cleaner.
3. For wet vacuuming use the narrow brush D5, after the prior removal of hair from it, or the
crevice nozzle D3. Do not suck in the water with other nozzles.
4. After turning on the appliance, vacuum the wet surfaces. Suck in only the water with the appli-
cation of the vacuum cleaner. Do not suck in other liquids.
Fig.2
