I
C ARANCIO
A AZZURRO
B BIANCO
L BLU
G GIALLO
H GRIGIO
M MARRONE
N NERO
S ROSA
R ROSSO
V VERDE
Z VIOLA
GB
C ORANGE
A LIGHT BLUE
B WHITE
L BLUE
G YELLOW
H GREY
M BROWN
N BLACK
S PINK
R RED
V GREEN
Z VIOLET
F
C ORANGE
A BLEU CIEL
B BLANC
L BLEU
G
JAUNE
H GRIS
M MARRON
N NOIR
S ROSE
R ROUGE
V VERT
Z VIOLET
D
C ORANGE
A HELLBLAU
B
WEISS
L
BLAU
G GELB
H GRAU
M BRAUN
N SCHWARZ
S HELLROT
R ROT
V GRÜN
Z VIOLETT
E
C NARANJA
A
AZUL
B BLANCO
L TURQUI
G AMARILLO
H GRIS
M MARRON
N NEGRO
S ROSA
R ROJO
V VERDE
Z VIOLETA

SCHEMA IMPIANTO ELETTRICO

-Alimentazione elettrica (12 VDC) / (24 VDC)-

ELECTRICAL WIRING DIAGRAM

-Electrical power supply (12 VDC) / (24 VDC)-
SCHEMA DE L'INSTALLATION ELECTRIQUE -Alimentation électrique (12 VDC) / (24 VDC)-
SCHEMA DER ELEKTRISCHEN ANSCHLÜSSE -Elektrische Stromversorgung (12 VDC) / (24 VDC)-

ESQUEMA ALAMBRICO

-Alimentación eléctrica (12 VDC) / (24 VDC)-
16/55
