Proline Promag 53
Schrauben-Anziehdrehmomente Promag L für ASME B16.5, Class 150
Nennweite
Druckstufe
[mm] [inch]
25 1 Class 150
40 1 ½ Class 150
50 2" Class 150
80 3" Class 150
100 4" Class 150
150 6" Class 150
200 8" Class 150
250 10" Class 150
300 12" Class 150
350 14" Class 150
400 16" Class 150
450 18" Class 150
500 20" Class 150
600 24" Class 150
Schrauben-Anziehdrehmomente Promag L für AWWA C207, Class D
Nennweite AWWA
Druckstufe
[mm] [inch]
700 28" Class D
750 30" Class D
800 32" Class D
900 36" Class D
1000 40" Class D
1050 42" Class D
1200 48" Class D
1350 54" Class D
1500 60" Class D
1650 66" Class D
1800 72" Class D
2000 78" Class D
2150 84" Class D
2300 90" Class D
Endress+Hauser
ASME Schrauben
[lbs]
4 × 5/8"
4 × 5/8"
4 × 5/8"
4 × 5/8"
8 × 5/8"
8 × ¾"
8 × ¾"
12 × 7/8"
12 × 7/8"
12 × 1"
16 × 1"
16 × 1 ¹⁄₈"
20 × 1 ¹⁄₈"
20 × 1 ¼"
Schrauben
28 × 1 ¼"
28 × 1 ¼"
28 × 1 ½"
32 × 1 ½"
36 × 1 ½"
36 × 1 ½"
44 × 1 ½"
44 × 1 ¾"
52 × 1 ¾"
52 × 1 ¾"
60 × 1 ¾"
64 × 2"
64 × 2"
68 × 2 ¼"
Max. Anziehdrehmoment
Hartgummi
[Nm] [lbf · ft]
- -
- -
- -
- -
- -
- -
- -
- -
- -
135 100
128 94
204 150
183 135
268 198
Max. Anziehdrehmoment
Hartgummi
[Nm] [lbf · ft] [Nm]
247 182 292
287 212 302
394 291 422
419 309 430
420 310 477
528 389 518
552 407 531
730 538
758 559
946 698
975 719
853 629
931 687
1048 773
Polyurethan
[Nm] [lbf · ft] [Nm]
5 4 14
10 7 21
15 11 40
25 18 65
20 15 44
45 33 90
65 48 87
126 93 151
146 108 177
158 117
150 111
234 173
217 160
307 226
Polyurethan
[lbf · ft] [Nm]
215 -
223 -
311 -
317 -
352 -
382 -
392 -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
Montage
PTFE
[lbf · ft]
13
15
29
48
32
66
64
112
131
- -
- -
- -
- -
- -
PTFE
[lbf · ft]
-
-
-
-
-
-
-
-
-
-
-
-
-
-
23
