GB
MT
• Spindle lock (3)
• Locks the spindle when attach-
ing/removing the attachment
tool.
• Lock (14)
• Unlock milling depth adjust-
ment: Anticlockwise rotation
• Lock milling depth adjust-
ment: Clockwise rotation
• Button (4)
• Press: Enables coarse adjust-
ment of the milling depth
• Controller (9)
• Greater milling depth: Anti-
clockwise rotation
• Lower milling depth: Clockwise
rotation
• One complete revolution corres-
ponds to: 1 mm
• Switch lock (15)
• Locks the on/off switch against
unintentional operation.
• Unlocking: Press
Change collet chuck
Notes
• Only use the cutter with a shank
diameter suitable for the installed
collet chuck.
• Use only cutters that are suitable
for the speed of the power tool.
Tools and aids required
• Open-end wrench (17)
Procedure (Fig. A)
1. Turn the spindle lock (3) clock-
wise.
2. Use the combination wrench (17)
to screw off the coupling nut (5).
3. Pull the collet chuck out of the
coupling nut (5).
4. Loosely screw the required col-
let chuck (6, 18) back on with the
coupling nut (5).
30
5. Turn the spindle lock (3) anticlock-
wise.
Fitting and removing the
parallel guide
Fitting the parallel guide (Fig. D)
1. Loosen the wing screws (12).
2. Push the parallel guide (20) into
the holders (11).
3. Secure the parallel guide (20) with
the wing screws (12).
Removing the parallel guide (Fig. D)
1. Loosen the wing screws (12).
2. Pull out the parallel guide (20).
Fitting and removing cutters
To insert and replace cutters,
wear protective gloves to pre-
vent cuts and burns.
CAUTION! Tighten the coupling
nut (5) only when a cutter is inser-
ted. The collet chuck (6, 18) might get
damaged.
Procedure (Fig. C)
1. Turn the spindle lock (3) clock-
wise.
2. Loosen the coupling nut (5) with
the open-end spanner (17) as
much as needed, so that the cutter
can be inserted.
3. Insert the desired cutter into the
already mounted collet chuck
(6, 18). The cutter shaft must be
pushed in at least 20 mm.
4. Tighten the coupling nut (5) using
the combination wrench (17).
5. Turn the spindle lock (3) anticlock-
wise.
Setting the milling depth
Notes
•
WARNING! The milling depth
may only be set when the tool is
switched off.
