GB MT
• profiles on workpiece surfaces
made from wood, plastics and
lightweight materials.
The device is intended for use by
adults. Children under the age of 16
may not use the device, except under
supervision.
Any other use that is not expressly
permitted in this instruction manual
may pose a serious hazard to the
user and result in damage to the
device. The operator or user of the
machine is responsible for any acci-
dents or personal injury and/or ma-
terial damage to third parties or their
property. The machine is intended to
be used by do-it-yourselfers. It was
not designed for heavy commercial
use. The warranty is void in the case
of commercial use. The manufacturer
is not liable for damage caused by
improper use or incorrect operation.
The device is part of the
X 12 V TEAM series and can be
operated with batteries of the
X 12 V TEAM series. Batteries of
the X 12 V TEAM series may only
be charged using chargers of the
X 12 V TEAM series.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material
properly.
• Cordless Edge Router
• Adapter for external dust extraction
• Parallel guide
• Collet chuck, 8 mm (pre-as-
sembled)
• Collet chuck, 6 mm
• Open-end wrench
• 6-part cutter set
• Translation of the original instruc-
tions
24
Overview
The illustrations for the
device can be found on
the front and back fold-
out page.
1 On/off button
2 Handle
3 Spindle lock
4 Button
5 Coupling nut
6 Collet chuck, 8 mm
7 Baseplate
8 Recess
9 Controller
10 Locking screw
11 Mount (Parallel guide)
12 Retaining screw (Parallel guide)
13 Direction of rotation arrow
14 Lock
15 Switch lock
16 Charge level indicator on the
device
Accessories
17 Open-end wrench
18 Collet chuck, 6 mm
19 Adapter for external dust extrac-
tion
20 Parallel guide
21 Battery
22 Battery release
23 Charger
6-part cutter set
24 Profile cutter, ⌀25 mm, R 4 mm
25 Rounding cutter, ⌀22 mm,
R 6.3 mm
26 V-groove cutter, ⌀12.7 mm,
∡ 90°
27 Groove cutter, ⌀12 mm
28 Groove cutter, ⌀6 mm
