• AC Input
Model
Norminal AC
power[VA]
Norminal AC current
[A]
Max. AC current [A]
Rated grid voltage
(AC voltage range)
[V]
Rated grid
Frequency[Hz]
Power factor
• Battery
Model
Battery voltage
range [V]
Recommended
battery voltage [V]
Max.charge/
discharge power [W]
Bat 1 Max.charge/
discharge current [A]
Bat 2 Max.charge/
discharge current [A]
Bat 1 Peak charge/
discharge current [A]
Bat 2 Peak charge/
discharge current [A]
Communication
interfaces
Reverse connection
protection
88
X3-HYB- X3-HYB-
4.0-P 5.0-P
8000 10000
11.6 14.5
12.2 15.2
~1 (Adjustable from 0.8 leading to 0.8 lagging)
X3-HYB- X3-HYB-
4.0-P 5.0-P
"*" indicates that the current when Bat 1 and Bat 2 both work.
"*" indicates that the current when Bat 1 and Bat 2 both work.
X3-HYB- X3-HYB-
6.0-P 8.0-P
12000 16000
17.4 23.2
18.2 24.3
400V/380V
50/60
X3-HYB- X3-HYB-
6.0-P 8.0-P
130-800
400 VDC
1.1 Pn/2 Pn
30 (25*) d. c. A /30 (25*) d. c. A
30 (25*) d. c. A /30 (25*) d. c. A
CAN/RS485
Yes
X3-HYB- X3-HYB-
10.0-P 12.0-P
20000 20000
29.0 29.0
30.4 30.4
X3-HYB- X3-HYB-
10.0-P 12.0-P
X3-HYB-
15.0-P
20000
29.0
30.4
X3-HYB-
15.0-P
