No.
Required Material
1
PV wire
Communication
2
wire
3
PE wire
Battery wire (if
4
required)
* For users who purchased the product X3-Matebox G2, there is no need to prepare the
battery wire, because the battery wire has been included in the accessory pack . For specific
installation steps, please refer to X3-Matebox G2 Series Installation Manual.
• Cable and breaker recommended for Grid port connection
Model
Five-core
copper
cable
Breaker
• Cable and breaker recommended for EPS port connection
Model
Five-core
copper
cable
56
Type
Dedicated PV wire
Withstanding voltage: 1000 V
Withstanding temperature: 105 ℃
Fire resistance level: VW-1
Cable CAT5E
Conventional yellow and green
wire
UL cable
4kW
5kW
4-6 mm² 4-6 mm² 4-6 mm² 4-6 mm² 6 mm²
20 A
20 A
4kW
5kW
4-6 mm² 4-6 mm² 4-6 mm² 4-6 mm² 6 mm²
6kW
8kW
20 A
32 A
6kW
8kW
Conductor
Cross-section
4 mm²
/
6 mm²
6 mm²
10kW
12kW
6 mm²
40 A
40 A
10kW
12kW
6 mm²
15kW
6 mm²
40 A
15kW
6 mm²
