SolaX Power X3-HYB-G4 PRO Installationsanleitung Seite 69

PV Connection / PV-Anschluss / Connexion PV / Conexión FV / Ligação PV
(Fotovoltaica) / PV-aansluiting / Collegamento PV / Połączenie PV / Připojení FV /
Anslutning av solcellsanläggning / Conexiune PV / Връзка с PV / PV-tilslutning /
Σύνδεση φωτοβολταϊκού / PV-ühendus / PV-liitäntä / Fotonaponski priključak / PV
bekötés / Fotovoltinė jungtis / PV savienojums / Pripojenie fotovoltaiky (FV) / Povezava
fotonapetostnega kabla (PV) / PV Bağlantısı / Conexão PV
+
Wire stripper
1
2
+
-
3
4 ≤950 V
6
Remove caps from unused ports and cover the
ports with dustproof buckles.
-
+
-
Click!
+
-
+
-
5
*
According to the safety regulations, all unused ports must
be covered with dustproof buckles.
+
-
Click!
63
