8. Steps for connecting communication cable
1
1
Situation 1: Cable with RJ45 terminal
Situation 2: Cable without RJ45 terminal
3
* Repeat Step 3 if you need to connect another subport of Port COM 2. Go to the next step until all cables are threaded.
4
78
2
5
2
Pin 1: White & orange Pin 2: Orange
Pin 3: White & green
Pin 5: White & blue
Pin 7: White & brown
4
1
2
3
Remove
3
2
1
Pin 4: Blue
Pin 6: Green
Pin 8: Brown
Click!
1 8
M3
0.6 ± 0.1 N·m
