Item Description
A Bracket
B Positioning cardboard
C Positive PV pin contact
D Positive PV connector
E Negative PV pin contact
F Negative PV connector
Positive battery
G
connectors
Negative battery
H
connectors
I AC connector
J Disassembly tool
K Allen key
L Expansion tubes
M Self-tapping screws
N M5 screw
2
O 6 mm AC ferrule
2
P 4 mm AC ferrule*
Q RJ45 terminals
R RJ45 connector
S OT terminal
Disassembly tool for PV
T
connector
50
Quantity
1 pc
1 pc
2 pcs for 4 kW, 5 kW, and
6 kW inverters
3 pcs for 8 kW, 10 kW, 12
kW, and 15 kW inverters
2 pcs
2 pcs
1 pc
1 pc
1 pc
5 pcs
5 pcs
1 pc
10 pcs
10 pcs
12 pcs
1 pc
2 pcs
1 pc
Remarks
Used for connecting to the
PV port.
Used for connecting to the
battery port.
Used for tightening
the screw on the AC
connector.
Used to fix the bracket.
Used to fix the bracket.
Used to fix the inverter.
Used for wiring to Port
Grid&EPS. It's suitable for
all inverter models in this
series.
Used for wiring to Port
Grid&EPS. It's only suitable
for 4 kW, 5 kW, 6 kW, and
8 kW inverters.
Used for connecting to
subports of ports COM1
and COM2.
Used for connecting a CT.
Used for connecting
the ground wire to the
inverter.
