Installation
Packing List / Packliste / Liste du matériel livré / Lista de piezas / Lista da embalagem
/ Paklijst / Contenuto della confezione / Zawartość opakowania / Seznam balení /
Packlista / Listă de ambalare / Опаковъчен лист / Pakkeliste / Λίστα συσκευασίας
/ Pakkeleht / Pakkausluettelo / Popis pakiranja / Csomaglista / Pakuotės turinys /
Iepakojuma saraksts / Zoznam položiek balenia / Seznam pakiranja / kutu listesi / lista
de embalagem
Inverter
E F
Negative PV
Negative PV
pin contact
connector
L
Expansion tubes
P
2
4 mm AC ferrules
U
CT (Optional)
Z
M4 screw (Only for
Australia&New Zealand)
Item Description
/ Inverter
A
Bracket
G
Positive battery
connectors
M
Self-tapping screws
Q R
RJ45 RJ45
terminals connector
V W
Positive PV Negative PV
dustproof dustproof
buckles buckles
A1
Document
Quantity
1 pc
B
Positioning cardboard
H
Negative battery
connectors
N
M5 screw
S
OT terminal
X
Wire shielding cover (Only
for Australia&New Zealand)
Dongle
Remarks
C D
Positive PV Positive PV
pin contact connector
I J K
AC connector
Disassembly tool
Allen key
O
2
6 mm AC ferrules
T
Disassembly tool for
PV connector
Y
Bracket for wire
shielding cover (Only for
Australia&New Zealand)
