FIX I NG TH E MOU NTI NG B R ACKE T
• Check that the ceiling where you intend to mount the fan is stable and capable of safely
supporting the weight of the fan.
• Do not fix the mounting bracket directly on ceilings less than 10mm to avoid the risk of the
screw loosening and coming out.
• Mark the correct position of the holes and fix the mounting bracket using the screws with
metal anchors or screws and washers suitable for the type of ceiling chosen.
• Once the fixing bracket is installed, check its correct installation before hanging the fan.
The mounting bracket must support the entire weight of the fan.
M O TOR MOU N TI NG
Align the motor frame with the holes in the mounting bracket. Insert the four screws that
allow for attachment.
Tighten the screws twice to ensure that they are securely tightened.
E NGL I SH
10
Drill the necessary holes and then secure the
mounting bracket with the wood screws and wash-
ers to the ceiling joints.
Concrete roof
Drill holes with an 8mm drill bit, according to the
length of the expansion screws. Next, secure the
mounting bracket to the ceiling with the expansion
screws.
False ceiling
Drill the necessary holes and then fix the mounting
bracket with the special spring lever fixing screws
for use in false ceilings.
Wood roof
