Commissioning
Touch the function button to open the Calibrate p-sensor
t
mask and follow the instructions on the display:
Use the on-screen keyboard to enter the actual
t
atmospheric pressure.
Close all openings on the evaporator system.
t
Confirm the entry. The vacuum control starts
t
automatically.
Once the system is evacuated to a low level, the second calibration value can be entered: Wait
t
until the vacuum pump does not reduce the pressure further, i.e. until the minimum possible
vacuum pressure is reached.
Enter this value and confirm the values.
t
The calibration is then corrected based on the input values.
t
When the calibration process is canceled and the device is reset to the
factory settings, the default values are loaded!
Data logging
This menu item allows you to activate/deactivate the data recording function.
Data logging off display: Touch the function button to activate the function.
t
Data logging active: Touch the function button to deactivate the function.
t
Confirm your entry with [OK] to accept the change.
t
See "Data logging" on page 94 for detailed information.
Start process: Lift ...
Only variants with motor-driven lift: In this menu, define the behavior of the flask lift at the start of
the process.
Touch the function button to switch between the two options:
t
[Start process: Lift on]: With this selection, the flask lift automatically moves to the lower
y
end position when starting the process and the evaporation flask is thus automatically
immersed in the heating bath.
[Start process: Lift off]: With this selection, the flask lift remains in the upper end position
y
on starting the process; the evaporation flask must be immersed in the heating bath
manually.
Confirm your entry with [OK] to accept the selection.
t
Deactivate this function when using a foam brake and on devices using a
large evaporation flask to prevent damage to the flask!
