ASSEMBLY
STEP 1 - Disp�ay Pane�
�nsert the disp�ay pane� into the top and rear of
the stove. Be sure that the disp�ay pane� screen
is facing towards the front of the stove. Secure
the screen using two of the provided screws.
STEP 2 - Disp�ay Pane� Power Cord
This cord shou�d be wrapped up near the top of
the stove. �nsert the disp�ay pane� into the
groove on the back of the stove and attach it
with the two screws provided. P�ug free end of
cord into the back of the disp�ay pane�.
NOTE: This wire shou�d a�ready be connected
to the stove's power board. This connection can
be checked behind the access p�ate at the
bottom and rear of stove.
STEP 3 - Main Power Cord
The main power cord attaches to the stove at
the exposed socket in the rear of the stove.
Once any necessary assemb�y of the Disp�ay
pane� screen is comp�ete you may brief�y p�ug
your stove in and press red power button to ON
to make sure that it functions proper�y before
proceeding with insta��ation. Turn OFF and
unp�ug the stove once you con昀椀rm that the
disp�ay pane� works.
Caution: do not �eave the stove p�ugged
into any e�ectrica� supp�y during assemb�y
or insta��ation.
We o昀昀er on�y origina� spare parts.
STEP 4 - Fire pot
With the stove unp�ugged from any power
supp�y, the 昀椀re pot shou�d be inserted into the
stove so that it is secure�y positioned and a�so
the hot surface igniter shou�d be ab�e to make
physica� contact with pe��ets that wou�d be
he�d in the 昀椀re pot. See Figure 3.
A c�eaning too� is a�so packaged which faci�i-
tates safe�y c�eaning the 昀椀re pot perforations
of debris.
STEP 5 - Exhaust Duct Adapter
Locate the exhaust out�et pipe for your mode�
of stove. During assemb�y of the exhaust duct
adapter be sure to sandwich the sea�ing
gasket between the duct adapter and the
stove. Use four of the provided screws to
comp�ete the assemb�y. See Figure 4.
INSTALLATION
Warning: when this stove is not
proper�y insta��ed, a house 昀椀re may
resu�t. To reduce the risk of 昀椀re, fo��ow
the insta��ation instructions. Contact
�oca� bui�ding or 昀椀re o昀케cia�s about
restrictions and insta��ation inspection
requirements in your area.
Caution: any deviation or a�teration
from these insta��ation instructions
may resu�t in damage to you, the stove,
your chimney, and your home. Your
warranty may become void. Read and
fo��ow a�� instructions. Contact
C�eve�and iron works with any
comments, concerns, or questions.
Caution: contact �oca� bui�ding or 昀椀re
o昀케cia�s about restrictions and
insta��ation inspection requirements in
your area.
