TECHNICAL DATA
Pellet stove is advanced designed and has
individual fresh air input and venting system.
Negative pressure burning technology causes
high e昀케ciency and little ash outlet during
burning. It will be shut o昀昀 automatically by wrong
burning or lack of fuel. Large BTU, quick heating
and low fuel cost are its advantages.
Main Features
Modell P12
DIMENSIONS
Stove Dimensions LxWxH (mm) 593x543x1072
Stove Weight NET/GROSS (kg) 95/110
Air Inlet Pipe Diameter (mm) 50
Air Outlet Pipe Diameter (mm) 80
Pellet Hopper Capacity (kg) 28
OPERATION SPECIFICATIONS
Fuel
Heating Performance range(kW) 6,8-13,6
Room heating capacity (m³)
60-300
depend on house insulation
Consumption for Pellet
0,6-2,5
(Min-Max),(HR)
Automatic burning time
17-37
(Min-Max), (HR)
Stove Ef昀椀ciency 91,2%
CO2 content 9,8%
Carbon monoxide [at 13% O2]
69
/mg/Nmc
Dust (PM) [at 13% O2] /mg/Nmc 15
Exhaust air mass 昀氀ow (g/s) 7,6/4,9
Exhaust air temperature 178/92
ELECTRICAL SPECIFICATIONS
Electrical Supply Requirements
(V/HZ)
Average electrical consumption
Fuse (A)
Chimney draft requirement (Pa)
*BTU input/output will vary, depending on the brand of fuel you use in your Stove
** Depending on insulation rating of room and climate zone. Variations in climate
and location affect attributes such as stove ef昀椀ciency and CO produced.
GETTING STARTED
Thank you very much for purchasing our
products, you wi�� receive the fo��owing items in
the carton,
• Pe��et stove
• Disp�ay pane� *1
• Fire port * 1
• Cover *1 (on�y for P6, P9, P12)
• Main Power cord *1
• A��en Wrenches *2
• Screws *4
• Exhaust Connector *1
• Exhaust Connector si�icon pad *1
• Stove Feet *4
For repairs or adjustments, contact customer
service with the fo��owing information:
1. Equipment Mode�
2. Seria� number
3. Prob�em description (error code etc.)
We o昀昀er on�y origina� spare parts.
P9 P6 PR8
550x463x966 550x463x760 515*510*995
75/85 65/75 90/100
50 41 50
80 80 80
14 7,5 14
Wood Pellet
4,6-11 3-6 3-9
60-220 60-120 60-220
0,5-1,75 0,4-1,15 0,5-1,75
10,5-36 13-37 10,5-36
89% 84,3% 84,1%
9% 7,4% 8%
87 71 98
15 19 15
9,2/6,1 6,5/4,2 6,2/3,9
155/78 165/151 144/81
230/50
80
3
12/10
CLEARANCE TO COMBUSTIBLES
The fo��owing stated c�earances represent the
minimum distances between the stove and any
other object. No objects shou�d encroach into
this space. This inc�udes but is not �imited to
carpet, furniture, chi�dren, pets, c�othing, fue�,
or any other object. These c�earances may
on�y be reduced by means approved by the
regu�atory authority having jurisdiction.
FLOORING SPACE & CLEARANCES
When insta��ed on a combustib�e f�oor,
noncombustib�e f�oor protection is required to:
• Cover the area beneath the stove and
extend at �east 404mm to the front.
• Cover the area at �east 201 mm beyond
each side and 150mm beyond the rear of
the room heater.
• Cover the area under the exhaust venting
and 50.8mm beyond each side.
Additiona��y, the wood pe��et 昀椀re stove sha��
be positioned such that:
• �t has at �east 229 mm of c�earance from
each side to the nearest body.
• �t has at �east 239 mm of c�earance from
the rear to the nearest body.
• Vertica� runs of vent pipe must be at
�east77m from any wa��. Fina��y, the area
which the wood pe��et 昀椀re stove is insta��ed
sha�� have a f�oor-to-cei�ing distance of at
�east, 2134 mm.
UNPACKING
• Remove Stove from carton.
• Remove a�� protective packaging app�ied to
heater for shipment.
• Check Stove for any shipping damage.
�f any damage is found immediate�y contact us.
