3.2.3. Notes on the supplied power supply units
 Only use the plug-in power supply unit supplied with the device.
The mains socket must be easily accessible. If an operating error occurs, the power supply unit must be
unplugged from the socket immediately. The power supply unit is immediately ready for operation when it is
plugged into the socket. To switch off the mains adapter, it must be pulled out of the socket. Do not pull on
the cable when disconnecting it.
3.2.4. EOC 30-29 | EOC 30-49
EOC 30-29 | EOC 30-49 have a built-in power supply unit.
 Connect the device to a mains socket using the enclosed mains cable.
3.3. RF connections
3.3.1. EOC 30-01 | EOC 30-21 | EOC 30-29 | EOC 30-49
 Use a coaxial cable to connect the EoC+RF port to the feeding in point of the coax network (splitter,
combiner, terrestrial input of a multiswitch etc.).
3.3.2. EOC 30-02 | EOC 30-03
 Use a coaxial cable to connect the G.hn port to the on the antenna wall outlet.
