INTRODUCTION
Thank you for purchasing a Honda motor hoe.
This manual covers the operation and maintenance of the Honda
FG110 motor hoe.
We want to help you get the best results from your new motor hoe and
to operate it safely. This manual contains the information on how to do
that; please read it carefully.
This manual should be considered a permanent part of the motor hoe
and should remain with it if it is resold.
If you have a problem or questions concerning the motor hoe, contact
your supplying dealer.
We recommend that you read the warranty policy to fully understand
your rights and responsibilities. The warranty policy is a separate
document provided by your dealer.
Honda Power Equipment Mfg., Inc. reserves the right to make
changes at any time without notice and without incurring any
obligation.
No part of this publication may be reproduced without written
permission.
SAFETY MESSAGES
Your safety and the safety of others are very important. And using this
motor hoe is an important responsibility.
To help you make informed decisions about safety, we have provided
operating procedures and other information on labels and in this
manual. This information alerts you to potential hazards that could
hurt you or others.
Of course, it is not practical or possible to warn you about all the
hazards associated with operating or maintaining a motor hoe. You
must use your own good judgment.
Pay special attention to statements preceded by the following words:

DANGER

WARNING

CAUTION
Each message tells you what the hazard is, what can happen, and
what you can do to avoid or reduce injury.
Damage Prevention Messages
You will also see other important messages that are preceded by the
following word:
Your motor hoe or other property can be
NOTICE
damaged if you don't follow instructions.
The purpose of these messages is to help prevent damage to your
motor hoe, other property, or the environment.
00X39V25 0420
You WILL be KILLED or SERIOUSLY
HURT if you don't follow instructions.
You CAN be KILLED or SERIOUSLY
HURT if you don't follow instructions.
You CAN be HURT if you don't follow
instructions.
OWNER'S MANUAL
(Original instructions)
CONTENTS
MOTOR HOE SAFETY................. 2
IMPORTANT SAFETY
INFORMATION........................ 2
ATTACHMENTS AND
MODIFICATIONS .................... 2
SAFETY LABEL LOCATION ... 3
CONTROL LOCATIONS .............. 3
SETTING UP YOUR NEW
MOTOR HOE................................ 4
BEFORE OPERATION................. 4
ARE YOU READY TO
OPERATE THE MOTOR HOE?4
IS YOUR WORKING AREA
READY? .................................. 4
IS YOUR MOTOR HOE
READY TO GO?...................... 4
OPERATION................................. 5
SAFE OPERATING
PRECAUTIONS....................... 5
STARTING THE ENGINE........ 6
STOPPING THE ENGINE ....... 6
MOTOR HOE OPERATION .... 7
EM5
© 2016 American Honda Motor Co., Inc.-All Rights Reserved
ENGLISH
FG110
MOTOR HOE
SERVICING YOUR MOTOR HOE7
MAINTENANCE SAFETY ....... 8
MAINTENANCE SCHEDULE.. 8
ENGINE MAINTENANCE ....... 8
REFUELING .......................... 11
TRANSMISSION LUB ............12
TRANSPORTING....................... 13
STORAGE.................................. 13
TAKING CARE OF
UNEXPECTED PROBLEMS...... 14
TECHNICAL INFORMATION..... 15
SERIAL NUMBER LOC .........15
CARBURETOR
MODIFICATION FOR HIGH
ALTITUDE OPERATION ....... 15
EMISSION CONTROL
SYSTEM ................................15
SPECIFICATIONS ................ 16
CONSUMER INFORMATION .... 16
CUSTOMER SERVICE
INFORMATION ..................... 16
EC Declaration of Conformity,
Honda Distributor
Locations
...........................LAST PAGE
HPE.2016.03
K2
PRINTED IN U.S.A.
1
