3: transportation position
Adjust the depth according to the needs of your lawn.
1. Switch off the machine and wait for the machine to
come to a complete stop.
2. Remove the battery pack.
3. Pull the depth adjustment lever out of the detent and
set it to the desired position.
Depth Adjustment
D-1 D-2
Lever
MAINTENANCE
WARNING:
Before inspecting, cleaning or servicing
the machine, stop the motor, wait for all moving parts
to stop, and remove the battery pack. Failure to follow
these instructions can result in serious personal injury or
property damage.
WARNING:
Always wear eye protection with side
shields. Failure to do so could result in objects being
thrown into your eyes resulting in possible serious injury.
WARNING:
When servicing, use only identical
replacement parts. Use of any other parts can create a
hazard or cause product damage. To ensure safety and
reliability, all repairs, other than the items listed in these
maintenance instructions, should be performed by a
qualified service technician.
WARNING:
After striking a foreign object, stop the
machine, and remove the battery pack to make sure that
all moving parts have come to a complete stop. Then
inspect the machine for damage and make repairs before
restarting and operating the machine.
WARNING:
If the machine starts to vibrate
abnormally, stop the machine, and remove the battery
pack to make sure that all moving parts have come to
a complete stop. Then immediately inspect for damage,
replace or repair any damaged parts, and check for and
tighten any loose parts.
WARNING:
Be careful during adjustment of the
product to prevent entrapment of the fingers between
moving parts and fixed parts of the product.
CLEANING
WARNING:
When cleaning the dethatcher
attachment, DO NOT immerse it in water or other liquids.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
LUBRICATION
All of the bearings in this product are lubricated with a
sufficient amount of high-grade lubricant for the life of
the unit under normal operating conditions. Therefore, no
further bearing lubrication is required.
REPLACING THE CYLINDER
WARNING:
always remove the battery pack from the machine and
wait until the tine cylinder comes to a complete stop.
Wear protective gloves when handling the tines.
Depth Position
To remove the cylinder
1. Remove the battery pack from the power head.
2. Lay the attachment upside down on a flat stable surface.
3. Use the provided 5 mm hex key to loosen and remove
the two locking bolts on the bearing seat of the
dethatcher cylinder (Fig. E1).
4. Push the dethatcher cylinder leftwards until the spline
shaft on the right end is pulled out from the spline hub
of the machine (Fig. E2).
5. Remove the dethatcher cylinder from the machine
(Fig. E3).
E1-1 Bearing Seat
E2-1 Spindle Shaft
To install the new cylinder
1. Place the bearing seat of the new cylinder on the
machine base and push the cylinder leftwards as far
as it will go (Fig. F1).
2. Align and insert the spline shaft on the right side of the
cylinder into the spline hub of the machine (Fig. F2).
3. Align the two holes on the bearing seat with the holes
on the base, secure the bearing seat to the base with
the locking bolts (Fig. F3).
REPLACING THE RAKE TINES
Under normal use, rake tines can wear or break over time.
When adjusting the tine depth no longer gives you the
correct amount of dethatching, or if a tine breaks, follow
the steps below to replace the tines.
To remove the tine
1. Remove the battery pack from the power head.
2. Lay the attachment upside down on a flat stable
surface.
3. Push the two pins of the rake tine to the slot 1 on the
cylinder, and pull off the rake tine from the dethatcher
cylinder as shown in Fig. G.
DETHATCHER ATTACHMENT — DA1400
Before performing any maintenance,
Dethatcher
E1-2
Cylinder
E2-2 Spindle Hub
