Start-up
2. Switch on the appliance with
3. The display on the appliance shows Bat-
tery is being recharged. If not: see
chapter 10 "Help in case of malfunction",
page 49.
5.2 Making the basic settings
1. Open the cover flap.
2. Switch on the appliance with
code and type are displayed.
3. In the menu for language selection, select the
language with
4. In the Login > Enter PIN menu, enter the
preset PIN 0000. To do so, select the digit 0
with or in sequence and always ac-
cept with . After entering the PIN, access
is enabled.
5. In the Change PIN menu:
■
Under Enter new PIN, enter a self-se-
lected new four-digit PIN. To do so, se-
lect one digit in sequence with
and respectively confirm with
■
Under Reenter new PIN, enter the
new PIN again. If both entries are identi-
cal, PIN changed is displayed.
6. In the Enter date menu, set the current
date (format: DD.MM.20YY). To do so, select
one digit in sequence with
spectively confirm with
7. In the Enter time > HH:MM menu, set the
current time (format: HH:MM). To do so, se-
lect one digit in sequence with
respectively confirm with
The basic settings have been completed. The
Not calibrated Press Start key status
is displayed.
5.3 Setting the cutting height (14)
The cutting height can be manually adjusted con-
tinuously between 25 – 55 mm.
NOTE A cutting height of 55 mm is recom-
mended for the calibration run and for setting the
starting points.
1. Open the cover (14/1).
495761_c
.
. Firmware,
or and accept with
.
or and re-
.
or
.
2. Set the cutting height (the current cutting
height is displayed in the window (14/3) in
millimetres):
■
Increase the cutting height (i.e. lawn
height): Turn the rotary knob (14/2) clock-
wise (14/+).
■
Decrease the cutting height (i.e. lawn
height): Turn the rotary knob (14/2) anti-
clockwise (14/–).
3. Close the cover.
5.4 Carrying out an automatic calibration
movement
.
Place the appliance at the starting position
(13)
1. Place the appliance at the starting position in-
side the mowing area:
■
At least 1 m left and 1 m in front of the
base station
■
Aligned with the front side to the bound-
ary cable
Starting the calibration run
or
1. Check that there are no obstacles in the ex-
pected movement area of the appliance. The
appliance must be able to move over the
boundary cable with both front wheels at the
same time. If necessary, remove obstacles or
lay the cable temporarily inwards (min. 35 cm
required).
2. Start the appliance with
shown on the display:
■
! Caution ! Starting Motors
■
Calibration , Phase [1]
During the calibration run
and
To determine the signal strength inside the
boundary cable, the appliance first moves twice
straight beyond the boundary cable and then into
the base station and comes to a stop there.
■
The message Calibration completed is
shown on the display.
■
The battery is being charged.
NOTE The appliance must come to a stop
when it moves into the base station. If the appli-
ance does not touch the contacts when it moves
into the base station, it moves further along the
boundary cable. If the appliance moves through
the base station, the calibration procedure has
failed. In this case, the base station must be bet-
ter aligned and the calibration procedure repeat-
ed.
. The following is
