2.6 Product components
Make sure that all components have been received. Refer to
damaged, contact the manufacturer or a sales representative immediately.
Figure 2 Product components
1 NT3100sc
4
2 Wiper blade 1 mm or 2 mm (5x)
Section 3 Installation
Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the
document.
3.1 Installation guidelines
• Do not use stainless steel probes in sea water or other corrosion-causing media (e.g., acids,
alkalis, chlorine-based compounds). Clean the probe immediately.
• Make sure that the measuring medium does not cause damage to the probe components.
• Do not replace the cable. If the cable has damage, contact the manufacturer.
• Make sure that the device cables do not cause a trip hazard and do not have sharp bends.
• Make sure that the cable is not routed near hot surfaces. Make sure not to put heavy objects on
the cable.
• Make sure that there are no unwanted materials in the optical path.
• Immediately set the controller to OFF if the probe sends out smoke, noxious fumes or gets hot.
Contact the manufacturer.
3.2 Installation overview
Figure 3 shows the probe installed with the optional bracket installation option.
probe installed with the optional flow through unit. Refer to the documentation supplied with the
mounting hardware for more information.
4
The wiper type depends on the probe version.
Figure
4
3 Wiper blade
4 LZY261—Screw set, probe adapter for pole mount
C A U T I O N
2. If any items are missing or
5 mm (5x)
Figure 5 shows the
