GRINDING
1
Attach the grinding
guard 1
to the tool
and align it, so that the operator is pro-
tected from sparking.
Caution! Make sure the tool is
switched off and unplugged.
DEPRESSED GRINDING WHEEL
3a
Install the wheel with its raised centre
facing the machine. Install the outer
flange
5
with the smaller side facing
the grinding wheel.
Tighten the outer flange
5
wrench, while pressing the spindle lock
button 3.
CUTTING
1
Attach the cutting guard
2
to the tool
and align it, so that the operator is pro-
tected from sparking.
Caution! Make sure the tool is
switched off and unplugged.
DEPRESSED CUTTING WHEEL
3a
Install the wheel with its raised centre
pointing towards the machine and the
larger side of the outer flange
ing the cutting wheel. Tighten the outer
flange
5
with the wrench, while press-
ing the spindle lock button 3.
ON / OFF
1
To switch on the tool, push the on / off
switch 7
forward. Pressing the top part
of the on / off
7
switch locks it in on
position.
140
EN
2
Close the guard release lever. Securely
tighten the grinding guard
wrench.
STRAIGHT GRINDING WHEEL
3b
Install the grinding wheel with the
smaller side of the outer flange
ing the grinding wheel.
Tighten the outer flange
with the
wrench, while pressing the spindle lock
button 3.
2
Close the guard release lever. Securely
tighten the cutting guard
wrench.
STRAIGHT CUTTING WHEEL
3b
Install the cutting wheel with the larger
side of the outer flange
5
fac-
cutting wheel.
Tighten the outer flange
wrench, while pressing the spindle lock
button 3.
To switch off the tool, release the on /
off switch 7. If the switch is locked,
press the lower part of it to unlock it.
Let the wheel come to standstill with-
out applying pressure to its surface.
1
1. 1.
1
with the
2. 2.
3a
5
fac-
5
with the
1
2
with the
2. 2.
3a
5
facing the
5
with the
1
2
3b
2
2
1. 1.
3b
2
1. 1.
2. 2.
2. 2.
1. 1.
2. 2.
1. 1.
