Pairing
6.3.6 Separate door opener and day/
night mode switching
VCC
IN4
GND
OUT
NO
NC
IN2
COM
OUT2
IN3
ε
Figure 8
Connection of door openers with a
locking function and only one signal
input.
e.g. compatible with Winkhaus
blueMotion, Siegena GENIUS,
Roto Eneo
7
Pairing
Please read this entire section
before starting the pairing proce-
dure.
First of all, set up your
Homematic IP Home Control Unit
or Homematic IP Access Point
using the Homematic IP app to be
able to use other Homematic IP
devices in the system. Detailed
information on this can be found
in the operating instructions for
the Home Control Unit or Access
Point.
Proceed as follows to pair the device:
• Open the Homematic IP app on
your smartphone.
• Select the menu item "Pair device".
• After installation, the pairing mode
remains activated for 3 minutes.
You can manually start the pairing
mode for another 3 minutes by
briefly pressing the system button
(A).
Figure 9
Your device will automatically appear
in the Homematic IP app.
• To confirm, enter the last four dig-
its of the device number (SGTIN) in
your app, or scan the QR code. The
device number can be found on
the sticker supplied or attached to
the device.
• Wait until pairing is completed.
• If pairing was successful, the LED
(A) lights up green. The device is
now ready for use.
• If the LED lights up red, please try
again.
• In the app, give the device a name
and allocate it to a room.
• After installation, close the
flush-mounted box with a suita-
ble cover or a masking frame for
flush-mounted boxes.
21
