Battery removal and insertion
The battery can be removed from the cycle to prevent theft, for charging, or to be stored under optimal conditions.
Removing the battery:
Insert the supplied key into the lock on the frame and, after turning the key to
the release position, remove the battery from its seat on the frame.
The extraction the battery supplied with the Performance version will require a further unlocking procedure
by intervening on the device located on the battery.
Inserting the battery:
Insert the battery into its seat integrated with the cycle frame and secure it by turning the key to the locked position (if
provided).
Check that the battery is correctly installed and secured by trying to pull it out and/or making sure that it is securely fastened
to the frame and does not move.
Battery charging
Before using the electrically power assisted cycle for the first time, the battery must be fully charged using the battery charger
supplied.
The average time to fully charge the battery, which varies according to the residual charge level of the battery, can be
estimated as shown in the sheet below.
We recommend charging the battery with the specific battery charger after each use of the electrically power assisted
cycle.
CAUTION
Only use the battery charger provided or an approved model with the same technical specifications, taking care to observe
the same methods and precautions of use indicated on the charger or in the manual.
EPAC
Performance Pro
Performance Pro +
Performance
Performance +
Make sure that the electrically power assisted cycle is switched off and the battery is switched off/disabled (if required by the
model of battery supplied with the bike).
Make sure that the battery charger, its jack and the charging port of the battery are dry.
Connect the battery charger jack to the battery charging port and then, the mains power socket (230V/50Hz).
There is a red indicator light when the battery is charging. When the indicator light turns green, it signals that the battery
charging cycle has been completed.
Disconnect the battery charger jack from the battery charging port and then, the mains power socket.
A. Battery charging jack
B. Power supply jack
C. Battery charging LED indicator light
Battery charger INPUT
AC 100V-240V 1.8A (Max)
AC 100V-240V 1.8A (Max)
AC 100V-240V 1.8A (Max)
AC 100V-240V 1.8A (Max)
Battery charger OUTPUT
DC 42V 2.0A (Max)
DC 42V 2.0A (Max)
DC 42V 2.0A (Max)
DC 42V 2.0A (Max)
32
Recharge life
5-7 h
5-7 h
5-7 h
5-7 h
