Front wheel installation
Insert the front wheel into the appropriate fork housings (dropouts) and tighten using the appropriate quick release device
Lever Pin Locking nut
Conical springs*
*Conical springs: position the end of the conical springs (those with the smallest diameter) in the direction of the wheel.
Insert the pin equipped with the relative conical spring inside the hub, leaving the lever on the right side of the cycle (side
without the brake disc); insert the second conical spring and the locking nut into the pin coming out of the hub on the
opposite side (side equipped with the brake disc), screwing it until it is flush against the dropout.
Close the lever towards the fork to complete the tightening operation by verifying that the lever has adequate resistance
during the closing phase (such as to leave a mark on the palm of the hand used to tighten the lever, so-called "imprint on
palm") and, after closing, requires a considerable force to be exerted to allow relative opening.
Installing and positioning the seat post
Insert the seat post into the seat tube of the frame and, after positioning the saddle correctly, secure the seat post firmly using
the special clamping device (seat post clamp) on the frame.
DANGER
Minimum insertion seat post insertion limit
For structural and safety reasons, it is strictly forbidden, when using the bike, to extract the seat post from the seat tube of
the frame beyond the limit indicated on the latter to avoid the risk of causing any structural fractures to the bike and incurring
serious injuries.
The seat post is deemed to be correctly and safely positioned inside the seat tube of the frame by inserting it so that no
markings and/or graphic indication of the minimum insertion limit can be seen; see:
