USING THE SHARK MATRIX
VAC & MOP 2-IN-1 SETUP
NOTE: Before it can mop, the robot MUST complete an Explore Run with the pad plate removed.
After the Explore Run, you will have an option to set up Carpet Zones and verify those carpets in the app
with a Carpet Verification Run. This ensures your robot will avoid carpets in mopping mode.
Attach the mopping pad by inserting the flat edge of
the pad through the slot in the Vac & Mop 2-in-1 Dust
Bin. Pull the mop pad all the way through the slot until
it is securely inserted.
Lift open the fill cap on the top of the reservoir. Add water
to the max fill line.. Close the cap and make sure it is
properly sealed.
PLUS 2-IN-1 ROBOT
™
Secure the pad to the Vac & Mop 2-in 1 Dust Bin.
Firmly push the Vac & Mop 2-in-1 Dust Bin into the
back of the robot, and ensure both latches click into
place. The CLEAN button on the robot will illuminate
blue when the Vac & Mop 2-in-1 Dust Bin is inserted
properly.
USING THE SHARK MATRIX
VAC & MOP 2-IN-1 SETUP
NOTE: Before the first mopping run, remove any rugs or mats from the robot's path. You can also prevent
your robot from traveling over rugs and carpets by setting up Carpet Zones in the app.
When the reservoir in the Vac & Mop 2-in-1 Dust Bin
has fluid and is properly installed, with the mopping
pad attached, the robot is ready to vacuum and mop
simultaneously. Press the CLEAN button on the robot
or in the app to start a vacuuming and mopping run.
The robot will pre-saturate the mopping pad before
starting its run.
To remove the mopping pad from the Vac & Mop
2-in-1 Dust Bin, detach the pad from the pad plate
and slide the pad out of the slot.
PLUS 2-IN-1 ROBOT
™
When mopping is complete, remove the Vac & Mop
2-in-1 Dust Bin by pressing the fill port button and
sliding it out. Empty the reservoir after each use.
The dust bin will auto-evacuate into the self-empty
base when the robot docks.
CAUTION: Floors may be slippery after mopping.
