GETTING TO KNOW YOUR SHARK MATRIX
Charge Indicator Lights
Error Indicator Light
Front Bumper
DOCK Button
Cliff Sensors
Battery Door
Cliff Sensors
Brushroll Door
Mopping Pad
Charging Contact
PLUS 2-IN-1 ROBOT
™
Wi-Fi Indicator Light
CLEAN Button
LIDAR Navigation
Module
Side Brush
Note: Side brush design
may vary
Front Caster
Wheel
Cliff Sensors
Brushroll
Drive Wheel
Self-Empty Dust
Bin and Filter
GETTING TO KNOW YOUR SHARK MATRIX
ROBOT DUST BIN
VAC & MOP 2-in-1 Dust Bin
Filter
Fill Port
Holds dry debris for vacuuming and water for mopping
Holds mopping pad and enables
mopping mode when attached to
the robot dust bin
SELF-EMPTY BASE
FRONT
Indicator Light
Base Dust Bin
Post-Motor
Filter Door
Charging Contacts
LANDING MAT
PLUS 2-IN-1 ROBOT
™
Release
Button
Pad Plate
SELF-EMPTY BASE
BACK
Release Button
Charger Cord
(This side up)
Pre-Motor
Filter Housing
