˜ LED work light
This product is equipped with a LED
work light to illuminate the immediate
[ ]
working area to improve visibility in poorly
lit areas.
The LED work light
o
automatically as soon as the product is
switched on.
NOTE
The LED work light
u
an additional approx. 10 seconds
after switching off the product.
˜ Working instructions
Torque
Smaller screws/bits can be damaged if
o
you set the torque or rotational speed
too high.
Hard screw joints (in metal)
Particularly high torque occurs, for
o
example in metal screw joints made
using drive sockets. Select a low
rotational speed.
Soft screw joints (e.g. in soft wood)
Again, use a low rotational speed, e.g.
o
to avoid damaging the surface of the
wood upon contact with the screw
head. Use a countersink.
Drilling in wood, metal and
other materials
Use a high speed for drill bits with
o
small diameter and a low speed for
drill bits with large diameter.
Select a low speed for hard materials
o
and a high speed for soft materials.
Secure or fasten the workpiece in a
o
clamp or vice (if possible).
Mark the spot where you want to drill
o
using a centre punch or nail. Select a
low rotational speed when starting.
42 GB/IE
lights up
[ ]
stays on for
[ ]
Pull the rotating drill bit from the hole
o
repeatedly to remove dust and chips
and clear the hole.
Drilling in metal
Use a metal drill (HSS). For optimum
o
results, cool the drill bit with cooling
lubricant (cutting oil). Metal drill bits
can also be used to drill into plastics.
Start with a 3 mm diameter drill bit and
then increase the size until the desired
hole diameter is achieved.
Drilling in wood
Use a wood drill with a lathe centre.
o
Deep holes: Use an auger bit.
Large-diameter holes: Use a
Forstner bit.
Small screws can be screwed directly
into soft wood.
NOTE
The product is equipped with
u
an electronic safety function for
kickback control. During operations,
the product shuts down during use
if there is a sudden or unexpected
jamming and blockage. This
additional safety feature reduces the
chance of serious injuries.
After clearing the jamming and
u
blockage: The product automatically
turns back to normal.
Belt clip
(Fig. J)
CAUTION! Risk of injury!
m
Before hanging the product in the
u
belt: Push the rotation direction
switch to the centre position
5 ] [
(lock). This prevents the product
from being switched on accidentally.
