3 . Tap {Done} to confirm the connection.
The battery pack
in the {Your tools} tab and can
be selected .
4 . Select the battery pack
information about the product can
be found in the {Your
if the battery pack is installed on
the product .
NOTE
If the connection status LED
u
not light up continuously:
Connect the product to the battery
pack .
10 ] [
Press and hold the on/off switch
for 5 seconds. The connection status
LED blinks for a few seconds
20 ] [
and lights up continuously . The
information about the product is
shown in the {Your
Upgrading the firmware can change
u
the features of the PARKSIDE app .
˜ Scope of delivery
WARNING!
m
The product and the packaging are
u
not children's toys! Children must
not play with plastic bags, sheets
and small parts! There is a danger of
choking and suffocation!
1 20V Cordless drill driver
1 Belt clip
1 Carrying case
1 User manual
˜ Parts description
Before reading, unfold the pages
containing the illustrations and familiarise
yourself with all functions of the product .
is listed
10 ] [
. The
10 ] [
tools} tab,
does
20 ] [
6 ] [
tools} tab.
Figure A:
Chuck
[ 1 ]
Chuck ring
[ 2 ]
Torque sleeve
3 ] [
Gear selector
4 ] [
Rotation direction switch/lock
[ 5 ]
On/off switch/speed control
[ 6 ]
Grip handle
[ 7 ]
Bit holder (magnetic)
[ 8 ]
Belt clip
[ 9 ]
Battery pack *
10 ] [
LED work light
[ 11 ]
Connection status LED
[ 20 ]
Figure B:
Battery pack *
[ 10 ]
Release button for battery pack
[ 12 ]
button (charging level)
13 ] [
Charging level LEDs (red/orange/
14 ] [
green)
Figure C:
Battery pack *
[ 10 ]
Battery charger (rapid battery
[ 15 ]
charger) *
Power cord with power plug
[ 16 ]
Charging control LED – Green
[ 17 ]
Charging control LED – Red
18 ] [
Not illustrated:
Carrying case
[ 19 ]
* Battery and rapid battery charger are
not included
˜ Technical data
20V Cordless drill
driver
Rated voltage:
Drill chuck type:
Gearbox:
No-load speed n :
0
1 gear:
st
2 gear:
nd
Max . torque:
PABSP 20 Li C4
20 V
keyless chuck
2 speed
0–500 min
–1
0–2000 min
–1
60 N m
GB 9
