• Any other use exceeds authorization.
The manufacturer is not responsible for
any damages resulting from unauthor-
ized use; risk is the sole responsibility of
the operator.
Please note that our equipment has not
been designed for use in commercial, trade
or industrial applications. Our warranty will
be voided if the equipment is used in com-
mercial, trade or industrial businesses or for
equivalent purposes.
m Remaining hazards
The machine has been built using mod-
ern technology in accordance with rec-
ognized safety rules. Some remaining
hazards, however, may still exist.
• The splitting tool can cause injuries to
fingers and hands if the wood is incor-
rectly guided or supported.
• Thrown pieces can lead to injury if the
work piece is not correctly placed or
held.
• Injury through electric current if incorrect
electric connection leads are used.
• Even when all safety measures are tak-
en, some remaining hazards which are
not yet evident may still be present.
• Remaining hazards can be minimized by
following the safety instructions as well
as the instructions in the chapter Author-
ized use and in the entire operating man-
ual.
Transport
Transport by hand, Fig. 3
For transport, the splitting knife A must be
completely moved down. Slightly tilt the log
splitter with handle B on the splitting column
until the machine is inclined on the wheels
and can be moved.
Transport by crane:
Never lift the machine on the splitting
knife!
Storing conditions:
The following conditions are required:
• Dry storing place under roof
• Maximum humidity 80 %
• Temperature range -20 °C to +60 °C
18
The machine should operate under the fol-
lowing environmental conditions:
minimum
Tempe- 5 C°
rature
Humidity
Setting up
Prepare the work place where the machine
is to stand. Create sufficient space in order
to allow safe working without disturbance.
The machine has been designed for work-
ing on a level surface. It must therefore be
set up in a stable position on firm ground.
Assembly
For reasons of packing, your scheppach log
splitter is not completely assembled.
Attaching the wheels, Fig 4 / Fig. 4.1
• Tilt the splitter forwards.
• Push the wheel axle (A) into the mounting
bracket (B) from below.
• Then reposition the splitter on the floor.
• Tighten the hex-nut (C) to secure the
wheel.
Carry out this procedure on both sides.
maxi- recom-
mum mended
40 C° 16 C°
95 % 70 %
