Manufacturer
scheppach Fabrikation von
Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Note
In accordance with valid product liability
laws, the manufacturer of this machine shall
not be responsible for damage to and from
this machine which results from:
• Improper care.
• Noncompliance with the Operating In-
structions.
• Repairs made by unauthorized persons.
• The installation and use of any parts
which are not original replacement parts.
• Improper use and application.
• Failure of the electrical system as a re-
sult of noncompliance with the legal and
applicable electrical directives and VDE
regulations 0100, DIN 57113 / VDE 0113.
We recommend
that you read through the entire operating
instructions before putting the machine into
operation.
These operating instructions are to assist
you in getting to know your machine and
utilize its proper applications.
The operating instructions contain important
notes on how you work with the machine
safely, expertly, and economically, and how
you can avoid hazards, save repair costs,
reduce downtime and increase the reliability
and service life of the machine.
In addition to the safety requirements con-
tained in these operating instructions, you
must be careful to observe your country's
applicable regulations.
The operating instructions must always be
near the machine. Put them in a plastic
folder to protect them from dirt and humid-
ity. They must be read by every operator
before beginning work and observed con-
scientiously. Only persons who have been
trained in the use of the machine and have
been informed of the various dangers may
work with the machine. The required mini-
mum age must be observed.
In addition to the safety requirements in
these operating instructions and your coun-
try's applicable regulations, you should ob-
serve the generally recognized technical
rules concerning the operation of wood-
working machines.
General notes
• After unpacking, check all parts for any
transport damage. Inform the supplier
immediately of any faults. Later com-
plaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize
yourself with the machine by carefully
reading these instructions.
• Only use original accessories, wearing or
replacement parts. You can find spare parts
at your scheppach dealer.
• When ordering, include our item number
and the type and year of construction of
the machine. For controls and parts see
Fig. 1 to 3.
Controls and Parts, Fig. 1+2
Handle
1
Splitting blade
2
Splitting column
3
Clamping claw
4
Operating arm
5
Grip protection
6
Bracket for table (front)
7
Bracket for table (side)
8
Table locking screw
9
Splitting table
10
Ventilation cap/oil filler plug
11
Basic frame
12
Wheel
13
Switches and plug
14
Stroke adjustment bar
15
Motor
16
HL710
Hydraulic log splitter
Operating instrucions
Technical data
Dimensions
D/W/H
Table heigh
mm
Working
heigh mm
Accessory pack
850/1220/1480
280/535/790
900
