U3
1 Scope of supply
• 1 U3 force transducer
• 1 U3 Operating Manual
Accessories (not included in the scope of supply):
• 'complete adapter' for knuckle eye mounting
0.5-10 kN: Adapter with four M5x12 and four M5x16 screws
20 kN: Adapter with four M10x25 and four M10x30 screws
50 kN: Adapter with eight M10x25 and eight M10x30 screws
100 kN: Adapter with eight M10x25 and eight M10x30 screws each
Property class 12.9. galvanized
• Knuckle eye ZGUW for 0.5-10 kN Order no. 1-U2A/1 t/ZGUW
2 Application information
Force transducers of the U3 type series are suitable for measuring tensile and
compressive forces. They measure static and dynamic forces extremely
accurately and therefore require careful handling. You must take particular
care when transporting and installing the devices. If you knock or drop the
transducers, this could permanently damage them.
The housing provides an elaborate seal to protect the sensitive strain gauge
applications and it is essential that this is preserved. You must be particularly
careful with the base of the housing, as this is extremely thin.
The limits for the permissible mechanical thermal and electrical stresses are
stated in the Specifications. It is essential that these are taken into considera­
tion in planning the measuring set‐up, during installation and finally, during
operation.
A2113-2.0 en/de/fr
20 kN Order no. 1-U2A/2 t/ZGUW
50 kN Order no. 1-U2A/5 t/ZGUW
100 kN Order no. 1-Z4/100 kN/ZGUW
Order no. 2-9289.1956
Order no. 2-9289.1957
Order no. 2-9289.1958
Order no. 2-9289.2280
