DM600MAX
10. Resistance Measurement and Continuity Test
Range
400.0Ω
4.000kΩ
40.00kΩ
400.0kΩ
4.000MΩ
40.00MΩ
1. The accuracy specifications are applicable only when the offset is compensated by
REL function.
2. 40.00MΩ range is always in Low Resolution (4000 digits) mode.
3. Max. Open Circuit Voltage: -1.3V @ 400.0Ω, -0.5V @ other ranges.
4. Max. Short Test Current: Approx. 0.1mA
5. Continuity Threshold: Adjustable from 10 to 50 Ω, default < 30Ω
6. Continuity Indicator: 2.7kHz Buzzer
11. Diode Measurement
Range
2.000V
1. Low Resolution mode only.
2. Maximum Open Circuit Voltage: Approx. 2.5V
3. Maximum Short Test Current: Approx. ±1mA
12. Capacitance Measurement
Range
40.00nF
400.0nF
4.000μF
40.00μF
400.0μF
4.000mF
40.00mF
1. Low Resolution (4000 digits) mode only.
2. The accuracy specifications are applicable only when the offset is compensated by
REL function.
13. Temperature Measurement
Range
-328.0°F to 2192°F
-200.0°C to 1200°C
1. The accuracy specifications are only applicable under lowest brightness within
15-minute operation time when the temperature is stable within ±1°C and the
instrument has been left for more than 2 hours in OFF state.
2. The accuracy specifications don't include the error of the thermocouple probe.
3. Low resolution mode only.
OL Reading
400.0Ω
4.000kΩ
40.00kΩ
400.0kΩ
4.000MΩ
40.00MΩ
OL Reading
2.000V
OL Reading
40.00nF
400.0nF
4.000μF
40.00μF
400.0μF
4.000mF
40.00mF
OL Reading
-364.0°F and 2408°F
-220.0°C and 1320°C
26
EN
Accuracy
0.2% + 5D
0.2% + 1D
1.0% + 1D
2.0% + 5D
Accuracy
1.5% + 2D
Accuracy
1.2% + 20D
0.9% + 10D
0.9% + 2D
2.0% + 20D
Accuracy
1.0% + 54D
1.0% + 30D
