DM600MAX
3. Current Measurement
• DC mode
Range
400.0μA
4000μA
40.00mA
400.0mA
4.000A
10.00A
• AC mode
Range
OL Reading
400.0μA
4000μA
40.00mA
400.0mA
4.000A
10.00A
1. Below 10% of range of AC mode, add 2D to the accuracy.
2. Max. Continuous Measuring Time
• No limit @ mA input terminal.
• Max. 1 minutes for 10A measurement with 10 minutes rest time @ 10A input terminal.
3. Overload Protection: Fast-acting fuse 440mA/1000V @ mA inputs
4. 30A Current Measurement with 30A Probe Accessory
Range
30.00A
1. 4000 digits (Low Resolution) mode only.
2. Frequency Response: 40Hz to 1kHz, DC
3. Accuracy specification includes the accuracy of 30A probe accessory.
4. Max. Measurement Time: 1 minute with 10 minutes rest time. (30A)
5. Overload Protection: Fast-acting fuse 30A/1000V in the 30A probe accessory.
5. HFR Measurement
1. Below < 200Hz, add 1% to AC accuracy.
2. When > 200Hz, HFR accuracy is unspecified.
3. Cut-off Frequency (-3dB): about 800Hz.
6. Peak Hold Measurement
1. Add 3% + 200D to AC accuracy.
2. For capture > 500μs repetitive peak signal.
3. Peak Hold accuracy is unspecified for < 1ms non-repetitive peak.
OL Reading
440.0μA
4400μA
44.00mA
440.0mA
4.400A
11.00A
40 to 70H
440.0μA
4400μA
44.00mA
1.0% + 2D
440.0mA
4.400A
11.00A
Fast-acting fuse 11A/1000V @ 10A inputs
OL Reading
33.00A
24
Accuracy
0.2% + 4D
0.2% + 2D
0.2% + 4D
0.2% + 2D
0.2% + 4D
0.2% + 2D
Accuracy
70 to 1kHz
1k to 3kHz
2.0% + 4D
1.5% + 2D
5.0% + 4D
Accuracy
3% + 5D
EN
