1. Voltage Measurement
• DC mode
Range
40.00mV
400.0mV
4.000V
40.00V
400.0V
1000V
• AC mode
OL
Range
Reading
40.00mV 44.00mV
400.0mV 440.0mV
4.000V 4.400V
40.00V 44.00V
400.0V 440.0V
1000V 1100V
1. Below 10% of range of AC mode, add 2D to the accuracy.
2. Below 5% of range of AC mode and the frequency is higher than 1kHz, the accuracy
is unspecified.
3. Input Impedance: 10MΩ, < 100pF
4. CMRR / NMRR (Common / Normal Mode Rejection Ratio):
VAC: CMRR > 60dB at DC, 50Hz / 60Hz
VDC: CMRR > 100dB at DC, 50Hz / 60Hz
The reading may deviate more than 0.04mV due to the heat of the backlight. The
accuracy specifications of 40mV and 400mV range are applicable after REL function is
used.
2. LoZ Voltage Measurement
Range
4.000V
40.00V
400.0V
1000V
1. Input Impedance: Approx. 3.5kΩ.
OL Reading
44.00mV
440.0mV
4.400V
44.00V
440.0V
1100V
15 to 40Hz 40 to 70Hz 70 to 1kHz 1k to 5kHz 5k to 20kHz
1.0% + 4D 0.5% + 2D 1.0% + 4D
OL Reading
4.400V
44.00V
440.0V
1100V
23
Accuracy
0.03% + 3D
0.03% + 1D
Accuracy
2.0% + 4D
Unspecified
DC Accuracy
1% + 3D
(15Hz to 1kHz)
EN
2.0% + 20D
Unspecified
AC Accuracy
2% + 5D
