DM600MAX EN
Continuity Check
CAUTION
• To avoid possible damage to the meter or to the equipment under test, disconnect
circuit power and discharge all high voltage capacitors before testing continuity.
The continuity check features a buzzer that sounds as long as a circuit is complete. The
buzzer allows you to quick continuity checks without watching the display.
When measuring resistance is less than threshold, the buzzer sounds. You can setup
the threshold in setup mode.
The continuity threshold is default 30Ω.
To use continuity check, turn the rotary switch to resistance position, then press F1 to
change measuring mode.
Testing Diodes
Use the diode test to check diodes, transistors, silicon controlled rectifiers (SCRs), and
other semiconductor devices.
For forward-bias readings on any semiconductor component, place the red test lead on
the component's positive terminal and place the black lead on the component's negative
17
