DM600MAX
Accessories (standard)
1. Alligator clip set
2. Test lead set - CAT III 1000V, CAT IV 600V, 10A, 120cm cable length
3. K Type Thermocouple
Accessories (option)
1. 30A Test Probe with alligator clip and built-in 30A Fuse
CAT III 1000V, CAT IV 600V, 30A
30A 1000V Fast-acting fuse.
120cm cable length
2. RPM Trigger Pickup (inductive)
Environmental Conditions
1. The accuracy specification is given as ± (% of reading + counts of least significant
digit) at 23°C ± 5°C, with relative humidity less than 80% R.H., and is specified for 1
year after calibration.
2. Temperature Coefficient: 0.1 * (Specified accuracy) / °C, < 18°C, > 28°C
3. Operating Temperature: -10°C to 30 °C (≤ 80% R.H.)
4. Storage Temperature: -20°C to 60 °C (≤ 80% R.H., no batteries)
5. Operating Altitude: 2000m (6562 ft)
6. Shock: 4 feet drop per EN 61010-1
7. Vibration: Random Vibration per MIL-PRF-28800F Class 2
8. For indoor use
9. Ingress Protection Ratings: IP67
Specification
For the 40000 digits (High resolution) mode, multiply the number of least significant digit
(counts) by 10.
Additional Specifications of AC Function
1. ACV and ACA specifications are ac coupled, true RMS.
2. For non-sinusoidal waveforms: Add 1.0% for C.F. 1.0 to 2.0
3. Max. Crest Factor of Input Signal: 3.0 @ full scale.
4. Accuracy of AC function is valid from 2% to 100% of the range.
5. Accuracy of Frequency Response is specified for sine waveform only.
30°C to 40 °C (≤ 75% R.H.)
40°C to 50 °C (≤ 45% R.H.)
Add 2.5% for C.F. 2.0 to 2.5
Add 4.0% for C.F. 2.5 to 3.0
22
EN
